TWO SPINDLE CNC2504SA Furniture Accessories Woodworking Machinewood Lathe
- Qingdao
- T/T Credit Card
You May Like
-
CNC1503S CNC Wood Lathe With Two Kives and Low Price
-
For T400*2500 CNC2504SA CNC Woodworking Lathe Machine
-
Wood Cnc Machine CNC2504SA Cnc Woodworking Lathe and Automatic Wood Lathe Machine
-
CNC2504SA Cnc Wood Lathe Price
-
Wood Lathe CNC2504SA Cnc Woodworking Lathe
-
CNC2504SA CNC Woodworking Lathe Machine With CE Certification
Product Details
| Condition | New | Brand Name | Haishu | |
| Model Number | CNC2504SA | Voltage | 380V/50HZ | |
| Power(W) | 5.5 | Weight | 1800 | |
| Dimension(L*W*H) | 3750*1400*1700mm | Certification | CE . ISO | |
| Warranty | one year | After-sales Service Provided | Overseas service center available |
Product Description
Technical Parameters
Brand name | Unit | Technical data |
CNC2504SA | ||
Max processing size | mm | T400*2500 |
Z-axis maximu moving distance | mm | 2550 |
X-axis maximum one-way moving distance
| mm | 250 |
Main drive form
|
| Independent spindles, frequency stepless
|
Spindle speed range
| r/min | 0-3500 |
Feeding speed | mm/min | 3000 |
Chuck diameter | mm | Φ160 |
Main motor power | kw | 5.5 |
Power supply |
| 380V/50HZ |
Dimensions (L * W *H) | mm | 3750×1400×1700 |
Net weight(Kg) | kg | 1800 |
The characteristics
A horizontal flat bed structure;
2, the spindle frequency stepless speed regulation;
3, X / Z-axis stepper drives;
4, bed rail for high-precision gauge;
5, precision ball screws, automatic forced lubrication;
6, duplex turret, roughing, finishing once completed;;
10. The control system uses sophisticated CNC controller, 12-inch color screen, the international standard G-code CNC language, supports a variety of software, support for technology extensions.
11, five-axis multifunction complete turning, milling, engraving, pull slots and other functions.
CNC2504SA CNC woodworking Lathe Use
Processing: staircase column, bending round, vases, tables, chairs legs, European furniture Roman, wooden hangers, washbasin and so on; cylindrical, conical, curved, spherical and other complex shapes rotator semi-finished wood products or wood .
The configuration
Standard configuration:
1,12 inch color screen, built-in CNC computer;
2, imported linear guide, precision ball screws;
3, engraving spindle and pull trough multifunction control section;
4, universal swivel joints;
5, the rotation center with the knife (5CM ~ 6CM wooden);
6, pneumatic feeding, automatic centering;
7, pneumatic material thimble;
8, V-type front steel tools;
9, with controls easy to use software, the basic pattern software;
10 randomly accompanied.
Select Configure
1, φ160 four jaw chuck linkage;
2, woodworking special vacuum cleaner;
3,220V constant power frequency spindle control;
Note: Customer-owned gas source, other configurations can be selected according to customer requirements.
