API Standards 1045 Piston Steel, Polished Rod,used Sucker Rod

FOB Price

US$ 1 - 620 / Piece

1 Piece(Min. Order)

Port Qiangdao
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Thickness	28.58, 38.10	Section Shape	Round
Outer Diameter	1.125 - 1.5 inch	Place of Origin	Shandong, China
Secondary Or Not	Non-secondary	Application	Drill Pipe
Certification	API	Surface Treatment	Other, Smooth
Special Pipe	API Pipe	Alloy Or Not	Is Alloy

Product Description

Introduction:

Polished Rods, it is designed and manufactured in accordance with the latest edition of the API specification 11B. Our polished rods and couplings are furnished with cold formed fully rolled threads. And they are made from fine quality alloy steel, featured by high strength, smooth surface and long service life. The tensile strength of polished rods are a range of 655 to 1102 Mpa. Regular polished rods are connected to polished rods coupling, and end upsetting polished rods are connected to sucker rod coupling in use. This technique ensures a perfect thread on each and every pin. The burnished thread surface that results from rolled threads improves resistance to corrosion and reduces abrasion within the thread. The work hardened flank provides increased surface tensile, yield and shear strength. Due to pressure deformation, a residual compresive stress system builds up at the thread root, which counteracts tensile loading. When compared to cut threads, the load capacity of rolled thread is increased by 6 – 12%.

Detailed Images

Usual Size Parameters:
1.Commom polished rod (API Spec 11B):

Size (inch)	Diameter of rod body OD（mm）	Thread nominal diameter (in)	With of sucker rod size (in)	Polished rod thread vanish cone BP4	Standard length L ±50(mm)
1-1/8	28.58 (+0.13,-0.25)	15/16 or 1 1/16	5/8 or 3/4	9°	2400/3400/4900/6700/7900/9100/11000/12200
1-1/4	31.75 (+0.13,-0.25)	1 3/16	7/8	9°	2400/3400/4900/6700/7900/9100/11000/12200
1-1/2	38.10 (+0.13,-0.25)	1 3/8	1	9°	2400/3400/4900/6700/7900/9100/11000/12200

2.End upsetting polished rod (SY/T5029-2006):

Size (inch)	Diameter of rod body OD（mm）	Upsetting end thread nominal diameter (in)	Not upsetting end thread nominal diameter (in)	With of sucker rod specifications (in)	Length of polished rods LK ±50（mm)
1	25.40 (+0.13,-0.25)	1 3/16	15/16	1 3/16	4500/6000/8000/10000/11000/12000
1-1/8	28.58 (+0.13,-0.25)	1 3/8	1 1/16	1 3/8	4500/6000/8000/10000/11000/12000
1-1/4	31.75 (+0.13,-0.25)	1 9/16	1 3/16	1 9/16	4500/6000/8000/10000/11000/12000

Types:

1.PISTON STEEL: Piston Steel is manufactured from a special quality medium carbon steel (1045) and designed for light to heavy loads where well fluids are non-corrosive. This polished rod has a minimum tensile strength of 100,000 PSI and is the best choice for heavy pumping applications where corrosion is not a problem.

Specifications:

1. Chemical Composition(%):

Type	C	Mn	Si	P	S
1045 Piston Steel	0.43-0.50	0.60-0.90	0.25 max	0.040 max	0.050 max

2. Mechanical Properties:

Type	Tensile Strength (Mpa)
1045 Piston Steel	620 min

Product Pictures
