Help CenterEN 10297 Seamless Steel Pipe E470 for Hydraulic Cylinders
Related Products
-
JIS G3445 STKM 19A Carbon Steel Tube for Mechanical TubeUS$ 600 - 820MOQ: 1 Ton -
JIS G3445 STKM 17A Hot Rolled Carbon Steel Tube for Mechanical PurposeUS$ 600 - 820MOQ: 1 Ton
-
STKM 16A Hot Rolled Carbon Steel Tube With Grinded and PeeledUS$ 600 - 820MOQ: 1 Ton
-
STKM 13A Hot Rolled Carbon Steel Tube for Mechanical PurposeUS$ 600 - 820MOQ: 1 Ton
-
STKM 12A Hot Rolled Carbon Steel Tube for Mechanical TubeUS$ 600 - 820MOQ: 1 Ton
Competitive Advantage:
High strength
High tenacity
Good harden ability
High resistance to thermal properties
Competitive price
Fast production lead time
Product Description:
Name: EN 10297 Seamless Steel Pipe E470 for Hydraulic Cylinders |
Standard:EN10297 Seamless Circular Steel Tubes for Mechanical and General Engineering Purposes |
Size: OD:21mm to 720mm; WT:2mm to 38mm; Length:12000mm(Max) |
Certification: The seamless steel pipe is supplied with 3.1.B inspection certificate,according to the standards EN 10207 and ISO 10474. |
Application: It can be made into mechanical and general engineering purposes. |
Surfaces Conditions: 1.Black surface with oxygen skin; |
|
Delivery Conditions:Hot Finished(+AR), Normolized(+N), Quenched and tempered(Q+T), etc.
|
Tube ends: The tube comes with square cut and deburred ends. |
Packaging: The hollow bar comes in strapped bundles. The minimum weight of each bundle is 2000kg; the maximum bundle weight being 5000kg, with a minimum of 4 pieces |
Delivery Time: 35 days after both parties confirmed. |
Chemical Composition(%):
C |
Si |
Mn |
V |
P |
S |
Al |
Nb |
Ti |
0.16/0.22 |
0.10/0.50 |
1.30 / 1.70 |
0.08 / 0.15 |
≤ 0.030 |
≤ 0.035 |
≤ 0.010 |
≤ 0.070 |
≤ 0.020 |
Mechanical Properties Minimum at room temperature
Steel Name |
Wall Thickness |
Rp 0.2 (MPa) |
Rm (MPa) |
A % |
20MnV6 / E470 |
≤ 16mm |
470 |
650 |
17 |
20MnV6 / E470 |
>16mm ≤ 40mm |
430 |
600 |
17 |
