Supplier for CK6130A Small CNC Turning Lathe Machine From Taian Haishu

Name: Supplier for CK6130A Small CNC Turning Lathe Machine From Taian Haishu
Brand: HAISHU
SKU: 128538999
Availability: InStock

Taian Haishu Machinery Co., Ltd.

US$ 6,500 - 7,000 MOQ: 1 Set

Key Specifications

Condition:

New

CNC or Not:

CNC

Place of Origin:

Shandong, China

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Condition New

CNC or Not CNC

Place of Origin Shandong, China

Brand Name HAISHU

Model Number CK6125A/CK6130A

Voltage 380v

Power(W) 3000

Dimension(L*W*H) 1650X1150X1500/1770X1200X1600

Weight 1000/1200

Certification ISO ,CE

After-sales Service Provided Engineers available to service machinery overseas

1.CNC system: GSK928,

2.Manual chuck ,

3.Manual tailstock,

4.Vertical four-station electric turret,

5.Automatic lubrication system,

6.Turning the cooling system.

Select configure

1.CNC system: GSK980, KND, Siemens, Fanuc, etc.,

2.Hydraulic chuck (solid and hollow), pneumatic chuck, manual collet, pneumatic collet;

3.Hydraulic tailstock, pneumatic tailstock,

4.Automatic feeder,

5.Horizontal six-station turret, tool row.

Item	Unit	Specifications
Item	Unit	CK6125A	CK6130A
Max. rotation diameter over bed	mm	Φ300
Max. rotation diameter over pallet	mm	Φ100
Max. workpiece length	mm	Collet 320/Chuck240	Collet 400/Chuck320
Spindle head form		A2-5
Spindle bore	mm	Φ48
Trombone hole diameter	mm	Φ40
X/Z repeat positioning accuracy	mm	0.012/0.013
X/Z maximum stroke	mm	280/350	280/400
X/Z fast-moving feed	mm/min	5000/10000
Spindle speed range	r/min	150-2200
Tailstock quill taper		MT-4
Tailstock quill stroke	mm	90	100
Main motor power	kw	3
Overall dimensions (L×W×H)	mm	1650×1150×1500	1770×1200×1600
Net weight	kg	1000	1220
