swiss automatic lathe CNC20Z-3 cnc lathe from taian haishu

Name: swiss automatic lathe CNC20Z-3 cnc lathe from taian haishu
Brand: HaiShu
Availability: InStock

FOB Price

US$ 50,000 - 80,000 / Set

1 Set(Min. Order)

Port qingdao
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Horizontal
CNC or Not	CNC	Automatic Grade	Automatic
Max. Swing Diameter	50mm	Place of Origin	Shandong, China
Brand Name	HaiShu	Model Number	CNC20Z-3
Voltage	380v 50hz	Power(W)	3700w
Dimension(LWH)	According to specific model	Weight	3500kg
Certification	ce,iso9001,tuv	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

swiss automatic lathe CNC20Z-3 cnc lathe from taian haishu

1 use imported NSK bearings, THK line rail screw, High progress and high life

2 no guide set, fixed set of free choice, Save material and high yield. Optional

conductance sets.Linkage guide set,Benefit is better.

3 spindle oil cooling type electric spindle, high speed and no dead angle cooling, than ordinary wind cooling electric spindle cooling more uniform, more performance.

4 this machine adopts the absolute operation, no need to switch back to the origin, time saving, labor.

5 flexible and changeable cutter design, matching freely.

6.24 hours continuously electricity, high efficiency, save labor

7.8 inventions, 26 utility model patents, the national patent office legal protection, and cooperation with the Wenzhou chamber of Commerce

8 the overall appearance is generous, the shape is novel and outstanding, and constantly improve and optimize

Standard configurations

spindle and countershaft are processing at the same time	√
C1/C2 axis Infinite Indexing	√
Lateral power head	√
No guide sleeve	√
Fixed guide sleeve	√
Linkage guide set (optional)	Option
Electric conductivity set (optional)	Option
Horizontal rigid tapping	√

Number of tools

out Diameter cutter number	5
Lateral power head	4
Frontal fixation	4
Frontal rotation	Option/2
Total tool number	13

Related parameters

Spindle parameters

Spindle hole diameter	The max. bar	Collet type	No set of guide technology	Spindle center to ground height	Spindle unlimited indexing	Spindle once feeding trip	C axis Minimum indexing	C axis Function
Φ22mm	Φ20mm	TsugamiS20	yes	1080mm	yes	180 mm(standard)200mm(Option)	0.001	yes

System parameters

OS	Spindle motor	Basal rotational speed	Maximum speed	Minimum setting unit	Control axis number	Hand wheel simulation
SYNTEC 20TA	3.7KW	10rpm/min	8000rpm/min	0.001mm	4	yes

X/Z axis

X axis stroke	Z axis stroke	Y axis stroke	X/Y/Z/X2/Y2/Z2 Fast feed speed	X/Y/Z/X2/Y2/Z2 axis Servo motor power
50mm	280mm	165mm	24m/min	0.75KW

Machine precision

X/Y/Z Repeat accuracy	X/Y/Z Positioning accuracy
±0.001	0.002

other

out Diameter tools number

inner Diameter tools number

Side milling tool

number

Out diameter toos spec.

Inner diameter tools spec.

Side milling tool spec.

size

power

weight

Power supply capacity

12*12

ER 11/16

ER 11/16×4

1800x1150x2140

8KVA

1260KG

8KVA

Select configuration

Synchronous rotating guide sleeve	Whirlwind milling	End milling cutter Power seat	Deep hole drilling	Back shaft power seat	Long material support device	Conveyer belt
yes	/	yes	/	/	yes	/
