Home > Products > Machine center > Machining Center Cnc Cnc Machine Center Cnc Vertical Machining Center
Machining Center Cnc Cnc Machine Center Cnc Vertical Machining Center
- QINGDAO
- Credit Card
You May Like
-
Cnc Machine Center Cnc Machining Center
-
Cnc Machine Center Cnc Machining Center Large Cnc Machining Center
-
Cnc Machining Center Vmc-800 Large Cnc Machining Center
-
Cnc Machining Center Vmc-800 Large Cnc Machining Center Cnc Horizontal Machining Center
-
3 Axis Cnc Machining Center Large Cnc Machining Center Cnc Horizontal Machining Center
-
CNC Milling Machine/Machining Center
Product Details
| Condition | New | Type | Horizontal | |
| Place of Origin | Shandong, China | Brand Name | Haishu | |
| Model Number | HMC800 | Voltage | 380v 3 phase | |
| Power(W) | 3.7kw | Weight | 20000 | |
| Certification | CE/ISO | Warranty | 1year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Item |
Unit | HMC800 |
Table travel(X,Y,Z) | mm | 1150×900×900 |
Table size | mm | 800×800 |
Max.load of worktable | kg | 2000 |
Worktable indexing |
| 1°×360° |
Worktable positioning accuracy |
| ±2” |
Worktable re-positioning accuracy |
| ±1.5” |
Rapid feed speed | m/min | 24 |
Spindle speed | r/min | 35~4500 |
Spindle torque | N.m | 1350 |
Tool shank type |
| BT50 |
Spindle ftont bearing diameter | mm | 100 |
Spindle motor power | kw | 22/26 |
Tool magazine capability | qty | 40( Chain ) |
Tool weight | kg | 25 |
(X,Y,Z) Positioning accuracy(X,Y,Z) | mm | ±0.0025 JIS |
(X,Y,Z) Repeat positioning accuracy(X,Y,Z) | mm | ±0.0015 JIS |
Machine weight | kg | 20000 |
Main configuratiom
Standard
1,FANUC 0i MD (FANUC 0i MD CNC system)
2,(Chain-type tool magazine capability 40 tools)
3,(Automatic chip conveyor)
Optional
SIEMENS 828D CNC system
Contact Us
- Taian Haishu Machinery Co., Ltd.
- Contact namebaoling su Chat Now
- Phone86-0538-8606169
- AddressZhouwangzhuang Village, Shankou Town, Daiyue Dist.
