Help CenterVMC1000 CNC Veritcal Machining Center With Low Price
Related Products
-
Vertical Cnc Machining Center VMC-850 Cnc Milling Machine CenterUS$ 25,000 - 45,000MOQ: 1 Set -
China VM850 CNC Milling Machine Center With Low Price From Gold Supplier Taian HaishuUS$ 26,000 - 36,000MOQ: 1 Set
-
XK7125 Cnc Milling Machine Center With Speed Spindle From Gold SupplierUS$ 17,500 - 18,000MOQ: 1 Set
-
XK7132 Cnc Milling Machine Center With Speed Spindle From Gold Supplier Taian HaishuUS$ 21,500 - 27,000MOQ: 1 Set
-
China Five Axis CNC Tool Grinder VIK-5B With CE Certification From Gold Supllier Taian HaishuUS$ 170,000 - 180,000MOQ: 1 Set
1. Specifications
Item |
Contents |
Units |
Specifications |
Table |
Table size |
mm |
1100×600 |
Number/Width/Distance of T-slot |
mm |
5-18-100 |
|
Max. load of table |
kg |
600 |
|
Travel |
Table travel(X,Y,Z) |
mm |
1000×600×550 |
Distance from spindle nose to table surface |
mm |
150~650 |
|
Distance from spindle axis to column guideway |
mm |
660 |
|
Feed |
Rapid feed speed(X,Y,Z) |
m/min |
48/48/36 |
Feed speed(X,Y,Z) |
mm/min |
25~10000 |
|
Spindle |
Taper of spindle |
|
BT40 |
Spindle speed range |
r/min |
40~6000 |
|
Spindle motor power |
kw |
7.5 11 |
|
Accuracy |
Positioning accuracy |
mm |
±0.015 |
Repeat positioning accuracy |
mm |
±0.0075 |
|
Overrall |
L×W×H |
mm |
2800×2200×2600 |
Weight |
Net weight |
kg |
5370 |
2. Main configuration
standard configuration
Fanuc DI mate -MD or GSK 25i cnc syatem
Turret -type tool magazine with 24 tools
RS232 interface seperated handwheel
Spindle blowing chip
Removel system
Optional configuration
FANUC 0i mateMD or Siemens 828D.
standard configuration
RND -2000M CNC system
Disc -type tools magazine
Capality 20 tools
Automatic chip removal system
GUARANTEE AND AFTER-SALE SERVICES:
1.one year guarantee for whole machine except of CNC system, which guarantee is three years
2.24-hours technical support by E-mail or telephone
3.User-friendly English software or Russian or Spanish, Users manuals and Detailed Videos/CD
4.Provide extra accessories for the machine
5.Also provide service of make program according to your drawings
6.Customized or special design is OK.
If you are interested in our products, welcome to leave a message or send the inquiry to understand the details of machine.
