Help CenterHigh Quality and Great Price XH7132 With Speed Spindle
Related Products
-
China Cnc Machining Cernter XH7132/VMC800 With High Speed Spindle MotorUS$ 25,000 - 34,000MOQ: 1 Set -
XK7132 Machinning Center Machine With Speed Spindle From Gold SupplierUS$ 21,500 - 27,000MOQ: 1 Set
-
XK7125 Cnc Milling Brake Disc Lathe for Cars With High Quality and Best PriceUS$ 17,500 - 18,000MOQ: 1 Set
-
Cnc Machining HMC800 Horizontal Machining Center and 5 Axis Cnc Machine PriceNegotiableMOQ: 1 Set
-
CNC MACHINE/MACHINING/MILLING CENTERUS$ 3,000 - 100,000MOQ: 1 Set
Specifications
Item |
Unit |
XH7125 |
XH7132(A) |
VMC800 |
Table travel(X,Y,Z) |
mm |
400×250×400 |
620×350×500 |
800×460×500 |
Table size |
mm |
600×250 |
920×320 |
800×460 |
Number/Width/Distance of T-slot |
mm |
3-14-75 |
3-14-85 |
3-18-150 |
Distance from spindle nose to table surface |
mm |
60~460 |
100~600 |
150~650 |
Distance from spindle axis to column guideway |
mm |
325 |
395 |
560 |
Taper of spindle |
|
BT30 |
BT40 |
BT40 |
Spindle speed range |
r/min |
60~6000 |
60~6000 |
40~6000 |
Spindle motor power |
kw |
3.7 (AC servo)3.7 |
3.7(5.5) (AC servo)3.7(5.5) |
7.5 (AC servo)7.5 |
Rapid traverse speed(X,Y,Z) |
m/min |
6 |
18 |
30/30/24 |
Cutting feed speed(X,Y,Z) |
mm/min |
2.5~3000 |
2.5~3000 |
2~10000 |
Tool magazinpability |
qty |
10 |
16 |
16 |
Max.dimension of tool |
mm |
φ92 |
φ120×200 |
φ130×300 |
Max.weight of tool |
kg |
5 |
8 |
8 |
Positioning accuracy |
mm |
±0.015 |
±0.015 |
±0.015 |
Repeat positioning accuracy |
mm |
±0.075 |
±0.0075 |
±0.0075 |
L×W×H |
mm |
1650×1600×2000 |
2020×1970×2160 |
2450×2200×2300 |
Net weight |
kg |
1530 |
2750 |
4650 |
Main configuration
Standard:
1,CNC system: GSK25i servo system.
2Spindle: Taiwan's high speed,precision spindle unit.
3,Tool magazine: Taiwan's armless library.
4,Ball screw: Taiwan's precision ball screw.
5,protection: full outer stainless steel inner defense and protection.
Optional:
KND-2000M,HNC-21M,FANUC 0i mateMD or Siemens 828D.
CNC fourth axis.
Automatic chip removal system.
