Home > Manufacturing & Processing Machinery > Machine Tools > CNC Machine Tools > Simence 808d SYSTEM XK7132 Vertical Machining Center From Taian Haishu
Simence 808d SYSTEM XK7132 Vertical Machining Center From Taian Haishu
US$ 9,000 - 18,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Horizontal
Brand Name:
Haishu
Payment & Shipping
Payment Methods:
Port of Shipment:
any port in China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Can be Fanic Sysytem VMC800 Horizontal Vmc Machine PriceNegotiableMOQ: 1 Set -
CNC VERTICAL MACHINING CENTER/ CNC Milling MachineUS$ 3,000 - 100,000MOQ: 1 Set
-
Chinese Cnc Machining Center VMC800 CNC Horizontal Cnc Center Machine From Gold SupplierNegotiableMOQ: 1 Set
-
China VMC800 CNC Horizontal Cnc Machining Center With CE CertificationNegotiableMOQ: 1 Set
-
Chinese 5-axis Machining Center VMC800 CNC Horizontal Cnc Machining Center From HAISHUNegotiableMOQ: 1 Set
Condition
New
Type
Horizontal
Brand Name
Haishu
Model Number
XK7132
Voltage
3.7kw
Power(W)
380v 3 phase
Dimension(L*W*H)
2500mm2260mm2300mm
Weight
2540kgs, 2540kgs
Certification
CE, CE
Warranty
one year
After-sales Service Provided
Overseas service center available
Simence 808d SYSTEM XK7132 vertical machining center from Taian haishu
Specification |
UNIT |
XK7132 |
Table size |
MM |
920*320 |
Spindle hole taper |
|
BT40 |
Travel range |
MM |
620*350*500 |
NO./width/distance of T-slot |
MM |
3-14-85 |
Max.load of table |
KG |
500 |
Distance from spindle nose to table surface |
MM |
100-600 |
Distance from spindle axis to vertical guideway |
MM |
395 |
Rapid feed speed |
M/MIN |
18 |
Feed speed |
MM/MIN |
2.5-3000 |
Spindle speed |
R/MIN |
40-6000 |
Spindle motor power |
KW |
3.7 |
Tool magazine capacity |
piece |
16 |
Max tool weight |
kg |
8 |
Max tool size |
mm |
Φ120*200 |
Positioning accuracy |
MM |
±0.015 |
Repeat position accuracy |
MM |
±0.0075 |
Overall dimension(L×W×H) |
MM |
2500×2260×2300 |
Net weight |
KG |
2540 |
Controller |
|
GSK25I |
XK7132 vertical machining center from Taian haishu
