Carbonation machine
QHS series drink mixer is designed and made for improving the proportion of water, syrup and carbon dioxide. It adopts foreign advanced technology—static mixer to lighten water layer, increase carbonizing time, assure mixing result and deoxying. It adopts high-quality water pump and
SEIMENS electrical equipment and other parts to form complete automatic control system. It has coordinating action, beautiful appearance, convenient washing, high automatic level and other
advantages. It is suitable for mixing all kinds of drink, such as soda water, fruit juice, cola and other soft and hard drink.
(1). Capacity : 1000~6000kg/h
(2). Range of proportion on syrup and water: 1:3 – 1:10
(3). Volume of Carbonation : (CO2: H2O in volume) 2: 5
(4). Mixing precise error: ≤2%
(5). Cooling water temperature in entry mouth : 0-4°C
(6). Cooling water pressure in entry mouth : 0.01-0.08Mpa
(7). Syrup temperature in entry mouth : 2-8°C
(8). Syrup pressure in entry mouth: 0.01-0.08Mpa
Drink dehydration method: Using carbon dioxide gas replacement of oxygen in the water
(9). CO2 pressure in entry mouth : 0.7-0.8Mpa
(10). CO2 pure % 99.9%
(11). Pressure for CO2 tank and syrup tank : 0.05-0.09Mpa
(12). Working pressure of tank : 0.2-0.5Mpa
(13). Total motor power: 6.3KW
(14). Overall dimension (long X wide X high): 2000X1600X2200mm
(15). Total weight: : 1700kg
