China Suppliers Insulation Performance is Good Temperature Compensation SF6 Monitor

China Suppliers Insulation Performance is Good Temperature Compensation SF6 Monitor thumbnail-1
China Suppliers Insulation Performance is Good Temperature Compensation SF6 Monitor photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shaanxi, China
Brand Name:
YS
Model Number:
MJ-II
Contact Supplier Request Quote Chat Now
Xian Yuanshun Electrical Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
XI'AN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shaanxi, China
Brand Name YS
Model Number MJ-II
Theory Other, see the specification
Usage Other, pressure switch electrical appliances industry
Size Other, according to the products details
Protect Feature Other, IP65
Contact Load Other, have contacts one or two or three

Specifications

1. Insulation performance is good

2.Temperature compensation SF6 monitor

3.beautiful appearance and small volume.



Features:

1. Temperature compensated bourdon tube pressure gauge

2. Suitable for indoor or outdoor installation

3. AISI304 hermetically sealed stainless steel case

4. AISI316 parts in contact with gas

5. Indicated values and signal outputs independent of installation altitude



Application:

1. Gas Insulated Switchgear (GIS)

2. Gas Insulated Lines (GIL)

3. SF6 circuit breakers

4. Gas insulated busbar systems



Description:



These instruments are used to monitor SF6 gas density in sealed tanks. They are applied to indicate gas density and to provide a signal outputs when the density reaches preset threshold values. They are designed to monitor Medium Voltage systems.



Parameter:



Nominal size:

63mm, 100mm

Scale range:

-0.1 to 0.9 MPa (customizable)

Accuracy:

20°C: Class 1.0 or 1.6; -20°C to +60°C: Class 2.5; -30°C to -20°C: Class 3.0

Degree of protection:

IP65

Ambient conditions:

-30°C to +60°C

Leakage rate:

< 1*10-9 Pa.m3/s (Helium mass spectrometer)

Pressure connector:

M20*1.5 (customized)

Location:

Bottom or back

Electrical connection:

Compact pluggable box with M20*1.5 cable gland

Cable size:

1.5mm; 2 recommended; 2.5mm maximum

Insulation properties:

Insulation resistance >100 MΩ (500V DC);

Withstand voltage 2kV, 50/60 Hz 1 min (to case)

Contact type:

Pointer driven magnetic snap action signal contacts;

80%Ag, 20%Ni, 10μm Au plated

Contact ratings:

30W/50VA, 1A max; 220VDC/380V 50/60Hz max

Window:

Safety glass

Weight:

1.1kg





Contact us:



Founded in 2010,Xi’an YuanShun Electrical Co., Ltd is located at the central business district of Economic and Technology Developing Zone, which is the new center of Xi’an City, Shaanxi, China. Xi’an YuanShun Electrical Co., Ltd is a high-tech industry company with intensive technology orientation, which is engaged in development, production, sales and technology service for SF6 gas industry.



We specialize in offering following products:

1. SF6 gauge

2. SF6 manometer

3. SF6 Density Monitor

Packaging

Items per Carton: 50 Pieces/Carton
Package Measurements: 1X1X1 cm
Gross Weight: 55.0 kg
