CK0625 horizontal mini cnc lathe machine with line tool
cl0625 with chuck ck0625 with colect ,
we cna produce ck0625 as your special need
Standard configuration:
CNC system: GSK928,
Pneumatic collet,
Tool row,
Automatic lubrication system,
Turning cooling system.
Select configure
CNC system: GSK980, KND, Siemens, Fanuc, etc.,
Manual chuck, pneumatic chuck, hydraulic chuck (solid and hollow),
Manual tailstock, pneumatic tailstock, hydraulic tailstock,
Automatic feeder,
Vertical four-station turret.
CK0625A cnc-machine-price in lathe with tailstock from haishu
also ck0625 cnc lathe can be with chuck
Technical data
Item |
Unit |
Specifications |
|||
CK0625A |
CK0632A |
CK0640A |
|||
|
Max. rotation diameter over bed |
mm |
Φ160 |
Φ230 |
Φ250 |
|
|
Max. rotation diameter over pallet |
mm |
Φ60 |
Φ80 |
Φ100 |
|
|
Max. workpiece length |
mm |
120 |
Collet 200/Chuck120 |
Collet 200/Chuck120 |
|
|
Spindle head form |
|
|
A2-5 |
A2-5 |
|
|
Spindle bore |
mm |
Φ33 |
Φ40 |
Φ48 |
|
|
Trombone hole diameter |
mm |
Φ25 |
Φ32 |
Φ40 |
|
|
|
mm |
220 |
260 |
260 |
|
|
X/Z repeat positioning accuracy |
mm |
0.012/0.013 |
|||
|
X/Z maximum stroke |
mm |
200/180 |
260/240 |
260/240 |
|
|
X/Z fast-moving feed |
mm/min |
5000/8000 |
|||
|
Spindle speed range |
r/min |
150-2200 |
|||
|
Main motor power |
kw |
2.2 |
3 |
3 |
|
|
Overall dimensions (L×W×H) |
mm |
1500×950×1500 |
1550×1000×1500 |
1600×1000×1550 |
|
|
Net weight |
kg |
850 |
950 |
1000 |
|
our shipping
our serive
we are big factory for cnc lathe machine , so can guve you good after-sale service , welcome you to reade with us by alibaba trade assurance
