Help CenterFrame for Plate Heat Exchanger Stainless Steel Refrigerator M15
Related Products
-
High Theta Carbon Steel Plate Price M15US$ 10 - 20MOQ: 10 Pieces -
304 ss Plate Price for Plate Heat Exchanger M20US$ 10 - 20MOQ: 10 Pieces
-
OEM Plate Heat Exchanger Plate Rubber Air to Air M15US$ 10 - 50MOQ: 10 Pieces
-
Air Cooler Heater Plate Heat Exchanger Frame M20US$ 50 - 100MOQ: 2 Pieces
-
Air Cool Plate Price for Plate Heat Exchanger High ThetaUS$ 3 - 10MOQ: 5 Pieces
Specifications
1.OEM&ODM2.High heat exchange efficiency
3.Safe operation
4.Easy to install
5.Long functional life
Plate
Special series
Safety heat exchangers
Stainless steel design for food and FDA applications
Compact double PHE-units including cocks and valves
Parameters |
S15D-II |
|
Heat transfer area of plate m2 |
0.62 |
|
Chevron depth mm |
4 |
|
Chevron angle º |
1 |
60 |
2 |
120 |
|
Chevron normal pitch mm |
13.78 |
|
Equivalent diameter mm |
8 |
|
Hole diameter mm |
150 |
|
Center Distance of holes mm |
H |
1294 |
W |
298 |
|
Center distance of suspension mm |
1567 |
|
Cross section ofsingle passage mm2 |
1804 |
|
Overall dimension of plate mm |
L |
1504 |
W |
500 |
|
|
The max. heat transfer coefficient (water to water)W/ m2.ºC |
7500 |
|
The max. Working temp.ºC |
180 |
|
The max. testing pressure Mpa |
2.0 |
|
The max. flow rate M3/h |
318 |
|
No. |
ASSY Area m2 |
No.of plate |
The max. testing pressure Mpa |
Dimension mm |
Theoretical weight(kg) |
||
L |
W |
H |
|||||
1 |
50 |
81 |
2.0 |
1040 |
630 |
1794 |
970 |
2 |
60 |
97 |
2.0 |
1140 |
630 |
1794 |
1020 |
3 |
70 |
113 |
2.0 |
1240 |
630 |
1794 |
1070 |
4 |
80 |
129 |
2.0 |
1340 |
630 |
1794 |
1120 |
5 |
90 |
145 |
2.0 |
1540 |
630 |
1794 |
1170 |
6 |
100 |
161 |
2.0 |
1640 |
630 |
1794 |
1220 |
