Air Cooler Heater Plate Heat Exchanger Frame M20

Air Cooler Heater Plate Heat Exchanger Frame M20 thumbnail-1
Air Cooler Heater Plate Heat Exchanger Frame M20 thumbnail-2
Air Cooler Heater Plate Heat Exchanger Frame M20 photo-1
Air Cooler Heater Plate Heat Exchanger Frame M20 photo-2
US$ 50 - 100 MOQ: 2 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Liaoning, China
Brand Name:
SUCCESS, SUCCESS
Model Number:
M20, M20
Contact Supplier Request Quote Chat Now
Liaoning Success Thermal Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Liaoning, China
Brand Name SUCCESS, SUCCESS
Model Number M20, M20
Type Other, Condenser, Plate Heat Exchanger
Application Refrigeration Parts
Certification Other, ISO9001:2008

Specifications

1.Reliability
2.High heat exchange efficiency
3.Safe operation
4.Easy to install
5.Long functional life

Parameters

S20D-II

Heat transfer area of plate m2

0.85

Chevron depth mm

4

Chevron angle º

1

60

2

120

Chevron normal pitch mm

15

Equivalent diameter mm

8

Hole diameter mm

200

Center Distance of holes mm

H

1478

W

341

Center distance of suspension mm

1810

Cross section ofsingle passage mm2

2184

Overall dimension of plate mm

L

1746

W

609

The max. heat transfer coefficient

                   (water to water)W/ m2.ºC

7500

The max. Working temp.ºC

180

The max. testing pressure Mpa

2.5

The max. flow rate M3/h

565







































































Liaoning Success Thermal Technology Co., Ltd is a highly dedicated company in the domain of development and manufacturing of heat exchangers at world-wide standards. The heat exchangers with up to 1500 m2 exchange surface are supplied for all usual industrial applications as well as for the ranges heating, climate, ventilation, food production, pharmaceuticals.

We are one of the largest manufacturers of plate heat exchangers, gaskets for plate heat exchangers, plates for plate heat exchangers, moulds for plate heat exchangers as well as other accessories related with plate heat exchanger in China.

Consistent development in the field of sealed plate heat exchangers has resulted in a wide variety of plate version with respect to surface structure, material and gaskets for various media on heat exchange.

Plate heat exchanger can offer additional flexibility by changing the number of plates. It can also be adapted to other thermal operating conditions.

Computer programs determine the optimum heat exchanger for your operation conditions based on latest technology.

We provide a wide range of plate heat exchangers to domestic and foreign customers with high quality and low price.



air cooler heater plate heat exchanger frame M20air cooler heater plate heat exchanger frame M20

Why us?

1 Fast delivery

2 High Quality

3 Competitive price

4 Reliability

5 More compact

 air cooler heater plate heat exchanger frame M20
