Hand Stacker PZ

Hand Stacker PZ photo-1
US$ 100 - 500 MOQ: 2 Pieces
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
YI-LIFT
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Jiangsu, China
Brand Name YI-LIFT
Model Number PZ
Type Manual Pallet Truck
Power Souce Other
Rated Loading Capacity 1000-2000kg
Max. Lifting Height 1500mm
Min. Lifting Height 85mm
Fork Length 1150mm, 1150MM
Fork Width 100/120
Overall Dimensions 1765*940*1980 PZ2015
Certification ISO9001
After-sales Service Provided No overseas service provided
  • Latest techology of hydraulic pump with less effort force. Top quality German seat kit.
  • Heavy duty 1 piece "C" section forks for greatest strength.
  • Optiin adjustable forks for wider opplications.
  • PZ series is economic range bult reliable.
  • Conforms to EN1757-1:2001 .
Model





PZ1015
PZ1515
PZ2015
Capacity
kg





1000
1500
2000
Load Centre
mm





500
500
500
Max. Fork Height
mm





1500
1500
1500
Lowered .Fork Height
mm





80
85
85
Fork Length
mm





1150
1150
1150
Fork Width
mm





100
120
120
Overall Fork Width
mm





224-730
252-900
252-900
Ground Clearance
mm





23
24
24
Min. Turning Radius(outside)
mm





1250
1350
1350
Front Load Roller
mm





80X43
80X70
80X70
Steering Wheel
mm





180X50
180X50
180X50
Overall Length
mm





1660
1715
1765
Overall Width
mm





700
940
940
Overall Height
mm





1998
1980
1980
Net Weight
Kg





180
252
284
Option adjustable fork available:346-710 mm forkwidth on PA series.


Note: Specification and materials are subject to change without notice.
