Modern Professional Two Roll Rubber Refiner Mixing Mill/Rubber Calender/Two Roll Mixing Mill

Name: Modern Professional Two Roll Rubber Refiner Mixing Mill/Rubber Calender/Two Roll Mixing Mill
Brand: Yahua
SKU: 128420759
Availability: InStock

Modern Professional Two Roll Rubber Refiner Mixing Mill/Rubber Calender/Two Roll Mixing Mill thumbnail-1

Modern Professional Two Roll Rubber Refiner Mixing Mill/Rubber Calender/Two Roll Mixing Mill photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

Yahua

Model Number:

Contact Supplier Request Quote Chat Now

Qingdao Yahua Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name Yahua

Model Number XK

Warranty ONe year

Specifications

1.Rollers are made of chilled iron
2.Rollers are smooth with two driving
3.High efficience protection

Rubber Refining Mill

CHARACTERISTICS

1. General Advantage :

1.1 high mixing perform

1.2 double driving

1.3 energy saving

1.4 easy operation

2 . Application

This machine is mainly used to plastic ,hot mill and mixing mill of natural and synthetic rubber for rubber product factory .

3. Feature and structure :

1. The rolls are made of chilled alloy cast iron with wear-resistant and hard surface.

2. The bored rolls can be cooled homogeneously.

3. The protective device is provided to protect the main parts from damage due to overload.

4. The reverse current plugging system is provided above the rolls. In case of emergency, the safety rod is pulled down and the rolls will stopped immediately.

5. Roll gap can be adjusted conveniently by turning the handwheel.

6. The bedplate of the machine is integral or separated, so the installation is convenient.

7. The transmission system adopts either hard tooth flank dual axis reducer or NGW hard tooth flank planet reducer, which has compact structure, lose noise an high efficiency.

8. The seal structure with special design can eliminate the leaking phenomenon of lubricating oil.

4.Version and Technique parameters:

	Xk-160	Xk-250	Xk-300	Xk-400	Xk-450	Xk-560	Xk-660
Working diameter of rolls(mm)	160	250	300	400	450	560	660
Working length of rolls(mm)	320	620	750	1000	1200	1530	2130
Front roll surface speed(m/min)	8.99	15.3	15.1	18.65	24.32	27.72	28.6
Friction ratio	1:1.35	1:1.1	1:1.27	1:1.27	1:1.27	1:1.2	1:1.24
Max.nip(mm)	4	8	8	10	15	15	15
Capacity per.batch(kg)	1-2	10-15	15-20	18-35	25-50	35-50	165
Motor power (kw)	5.5	18.5	22	37	55	90	245
Overall dimension(mm	*1160920** *1370	*31201322** *1500	*35801550** *1695	*43501850** *1780	*56702390** *1670	*58452284** *1978	*74653662** *2080
Weight(kg)	1000	4000	5200	7600	12000	23000	49000

5.Service after sale:

We give one year quality guarantee and long-term technical support. We also can train your workers for free. If you need, we can install and assemble the rubber mixing mill machine in your workshop. And you should pay for the necessary costs, according to the international tradition.

Qingdao Yahua Rubber Machinery is 100% RUBBER MACHINERY manufacturer

Passed CE&ISO9001:2008 certificate

As a bigger and quality rubber machine manufacture,we gain more and more clients. If you need ,please contact us as soon as possible.
