Specifications
1.used widely, good sales2.high working pressure
modious space and easy operation
4.saving energy, reliable action
PLC Auto Rubber Sealing Washer Vulcanizing Machine/Rubber Mat Making Machine
We are Qingdao Yahua Machinery CO.,LTD. Our main products are plate vulcanizing machine, curing press, rubber machine, conveyer belt vulcanizing press, Rubber crushing mill, Rubber refining mill, rubber tiles vulcanizing press, tire building machine, rubber kneader, two-roll mixing mill and so on.
The products have been exported to many countries, such as America, Canada, Australia, South Korea, and Southeast Asia, Middle-east, etc .
If you interested in our products mentioned above. Kindly let us know by return email.
Main technical parameters
| Model XLB-D | 400*400*1 | 400*400*2 | XLE-D450*450*1 | 500*500*1 | 500*500*2 |
| Nominal Mold Force(MN) | 0.80 | 0.80 | 0.80 | 0.80 | 0.80 |
| Plate Specification(mm) | 400*400 | 400*400 | 450*450 | 500*500 | 500*500 |
| Working Layer Number | 1 | 2 | 1 | 1 | 2 |
| Plunger Stroke(mm) | 250 | 250 | 300 | 250 | 300 |
| Plate Unit Pressure(Mpa) | 5.0 | 5.0 | 4.0 | 3.2 | 3.2 |
| Plate Distance(mm) | 250 | 125 | 300 | 250 | 150 |
| Plunger Diameter(mm) | 250 | 250 | 250 | 250 | 250 |
| Working Fluid Pressure( Mpa) | 16 | 16.2 | 16.3 | 16.2 | 16.2 |
| Total Heating Power | 6 | 9 | 6 | 7.2 | 9 |
| Heating Type | Electricity | Electricity | Electricity | Electricity | Electricity |
| Highest Temperature | 200°C | 200°C | 200°C | 200°C | 200°C |
| Structure Form | Pillar | Pillar | Crocodile | Pillar | Pillar |
| Motor Power | 1.5KW,940r/min | 1.5KW,940r/min | 2.2KW,960r/min | 1.5KW,940r/min | 1.5KW,940r/min |
| Dimension(length*width*height) | 1300×1400×650 | 1300×650×1400 | 1300×1400×650 | 1300×1400×650 | 1300×1400×650 |
Advantages
1. One person can simultaneously operate multi-stations to save labor costs.
2. Automatically enter or exit sliding mold, it is convenient to take out finished product. The operation is easy, even female operator can be competent the job.
3. Double sides operation, featuring simultaneously inter-lock function, it is safe for operation.
4. Fix up down mould to the sliding plate, and then it can start to produce. The speed of mould change is quick.
5. Control of each station is independently. According to the requirement of manufacture, requirement of maintenance, to decide station numbers. And then it can save electricity.
