Specifications
Automotive Rubber Bushing/Rubber Products Flat Curing Press1.high speed, inorout mold
2.PLC control,easy operation
3stabl
Automotive Rubber Products Curing Press
1.Main uses
The Curing Press mainly works for the clampdown of rubber ,which can be used as normal hydraulic machine.
We have both column and frame structure .
2.Advantages:
1, Real manufacturer meet all your inquiry.
2, Reasonable price for reasonable processing cost by strong self-production capacity.
3, good stability and good lighting performance.
4, Time counting,heating temperature stable and precise.
5,Keep pressure long time and lossless.pressure loss less than 5%.
6, Hydraulic system no leakage.
3. Technical Parameter as follows:
| Type | XLB-D300*300*1 | XLB-D350*350*2 | 500*500*2 | 800*800*1 | 1400*1700*2 | 2000*2000*2 | 1600*1800*1 |
| Nominal mounding power(MN) | 0.25 | 0.25 | 0.5 | 1.00 | 8.00 | 6.00 | 8.00 |
| Plate size(mm) | 300*300 | 350*350 | 500*500 | 800*800 | 1400*1700 | 2000*2000 | 1600*1800 |
| Working layer number | 1 | 2 | 2 | 1 | 2 | 2 | 1 |
| Piston stroke(mm) | 250 | 250 | 250 | 300 | 700 | 600 | 300 |
| Plate unit area pressure(Mpa) | 2.8 | 2.1 | 2.0 | 1.6 | 3.4 | 1.5 | 2.8 |
| Plate distance(mm) | 125 | 125 | 125 | 250 | 350 | 300 | 300 |
| Piston diameter(mm) | 152 | 152 | 200 | 300 | 400 | 340 | 400 |
| Working fluid pressure(Mpa) | 13.8 | 13.8 | 16.0 | 14.1 | 15.9 | 16.5 | 15.9 |
| Number of cylinder | 1 | 1 | 1 | 1 | 4 | 4 | 4 |
Meanwhile, we can produce different dimension your Parameter requirements. If you have any request, Pls dont feel any hesitate to contact with me anytime.
