Specifications
Thermosetting Rubber Curing Press Machine1.high speed, in/out mold
2.PLC control,easy operation
3.no oil leakage
Thermosetting Rubber Curing Press Machine
1.Main uses
The Curing Press mainly works for the clampdown of rubber ,which can be used as normal hydraulic machine.
We have both column and frame structure .
2.Advantages:
1. Automatic in/out mold and ejector, low labor strength
2. Optional normal valve or proportional valve, advanced way,
3. Matching, reduce energy consumption.
4. The electric system adoptPLC programming control, which is easy to be operated.
5. Plate Vulcanizer machine is used for all kind of vulcanizing mould ,rubber and plastic mould products,and non-products mould products.
6. Vulcanizer -for use in making vulcanized rubber work and heat-set plastic work, and may also be used to hydraulic press.
3. Technical Parameter as follows:
| Type | XLB-D300*300*1 | XLB-D350*350*2 | 500*500*2 | 800*800*1 | 1400*1700*2 | 2000*2000*2 | 1600*1800*1 |
| Nominal mounding power(MN) | 0.25 | 0.25 | 0.5 | 1.00 | 8.00 | 6.00 | 8.00 |
| Plate size(mm) | 300*300 | 350*350 | 500*500 | 800*800 | 1400*1700 | 2000*2000 | 1600*1800 |
| Working layer number | 1 | 2 | 2 | 1 | 2 | 2 | 1 |
| Piston stroke(mm) | 250 | 250 | 250 | 300 | 700 | 600 | 300 |
| Plate unit area pressure(Mpa) | 2.8 | 2.1 | 2.0 | 1.6 | 3.4 | 1.5 | 2.8 |
| Plate distance(mm) | 125 | 125 | 125 | 250 | 350 | 300 | 300 |
| Piston diameter(mm) | 152 | 152 | 200 | 300 | 400 | 340 | 400 |
| Working fluid pressure(Mpa) | 13.8 | 13.8 | 16.0 | 14.1 | 15.9 | 16.5 | 15.9 |
| Number of cylinder | 1 | 1 | 1 | 1 | 4 | 4 | 4 |
| Total heat power(kw) | 4.8 | 7.2 | 9.0 | 9.6 |
Meanwhile, we can produce different dimension your Parameter requirements. If you have any request, Pls dont feel any hesitate to contact with me anytime.
Contact Person: Bella Xue
Office phone: 0532-83132191
Office Fax: 0532-83137817
