PET semi-automatic Bottle stretch blowing molding machinery
Yosion machinery professional in making Semi-automatic bottle blowing machine( bottle blower, bottle blow molding machine), hand feeding automatic blowing machine , full automatic blowing machine .
Yosion's Semi-automatic PET bottle blowing molding machine is suitable for producing PET plastic containers and bottles in all shapes. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle and hot fill bottle etc.
Reasonable design,save power,Adopt high quality components.
Infrared oven heater adopts the quartz lamp to heat the PET tube.
Fully automatic process with low investment,high efficiency,quick and safe operation,easy for trouble-shooting,maintenance and other benefits.
We have perfect service after sales.welcome to comunication with us on line by MSN or Skype or Trade manager !
2012-6-18
- semi automatic machine
General Information: YS15-2 1 main machine &1 heater fitted with a far-infrared heater |
Product Volume: 0.2-1.5L |
Hourly Production : 0.6L 800-1000Pcs/Hr |
Heater power : 380V 5-10kw |
Blowing Air Compressor 2.0-3.0Mpa 0.4-0.5m3/min |
Working Air Compressor :0.8Map 0.3m3/min |
Mould Stroke : 150mm |
Mould Thickness / Width: 120-180mm 320mm |
Stretching Stroke :120-180mm |
Stretch Length:350mm |
Machine Weight : 800kg |
Machine Dimension :1320x580x1550mm 1600x580x1400mm |
*All specifications and designs are subject to change without notice |
- our hand feeding bottle blowing moulding machine
can make 1000pcs/hour , 2000pcs/hour ....
can be small mouth , widely mouth neck .
- our full automatic bottle blowing moulding machine:
...
