AR3260,SRU400,4 SIC,2 WSIC,4 XSIC,350W AC Power

Summary

1.10 slots, supports 3G and abundant wired interfaces, easy scalability
2.Data, voice, video, security, high performance for multi-services, non-blocking forwarding
3.Main control unit, fan, power redundant design, high availability
4.OSP ( Open Service Platform), co-create value
5.Mainly used in headquarters or large branch (500 users)

Characteristics

Applications in one box, Reduce TCO

The AR3200 routers reduce equipment and deployment costs due to the integrated routing, switching, 3G, LTE, voice, and security functions into a single device. At the same time, The AR3200 realizes enterprises flexible access with rich interfaces adapting to a variety of terminals.

Industry-Leading Voice Quality and User Experience

Enterprise-class voice communication is flexible and efficient, as the AR3200 voice features integrate with data networks.

• Basic voice functions are provided by the built-in PBX, SIP server, and SIP access gateway
• Value-added voice services include multi-party communication, IVR automatic connection, ring-back-tone, parallel ringing, sequential ringing, and one number link you (ONLY), bill management, and subscriber management.
• Intelligent call routing enables exceptional voice service reliability.
• The AR3200 routers can be connected with the NGN/IMS/PBX/terminal of major vendors.
• The Quality of Experience (QoE) feature monitors voice service quality in real time.
• Jitter buffer, echo cancellation, and packet loss compensation combine to deliver a superior user experience

Secure Service Access Protects Networks and Users

While delivering enterprise-class network services, the AR3260 router provides robust network security. Comprehensive security solutions include user access control, packet detection, and active attack defense.

• Features a built-in firewall and IPS, which acts as the first line of defense.
• Port authentication technologies include 802.1x authentication, MAC address authentication, and portal authentication.
• User and device authentication methods include RADIUS and HWTACACS.
• VPN technologies include IPSec VPN, GRE VPN, DSVPN, L2TP VPN and SSL VPN.

Integration of wireless and wired Functions

Wireless Access Modes

Wired Access Modes

Better Experience, Business Continuity

Multi-cores architecture, Industry-Leading performance

The AR3200 routers use a multi-core CPU and non-blocking switching structure to provide industry-leading system performance.

• The multi-core CPU speeds up concurrent data and voice service processing, supporting a large number of services.
• Achieves maximum traffic throughput with non-blocking switching.
• The bus channel bandwidth of a single slot is up to 10 Gbps.
• Delivers high performance and service reliability through independent protocol management, service processing, and data switching.

To meet enterprise requirements for network expansion and rapid service deployment, the AR3200 routers:

• Integrates routing and switching functions to simplify device configuration and maintenance by improving data switching efficiency between interface cards.

Low cost, High reliability

To guarantee the reliability of the equipment layer and network layer, the AR3200 series support hot-swap technology and redundant components design, a series of fault detection and judgment mechanisms, which can shorten the service interruption time.

• Assures service reliability and network stability with hot-swappable interface cards and redundant components, including fan modules.
• Link backup for enterprise services improves reliability.
• MS level Fault detection mechanisms, shorten the service interruption time
• Local survival, improve the voice reliability of branch network

Intelligent Service Deployment

As the enterprise grows, requirements for service deployment increase. To meet these growing demands, the AR3200 routers provide convenient configuration options:

• Mini-USB port to configure the devices using a GUI.
• USB drive to configure devices for plug-and-play.
• Auto-config feature to automatically distribute configurations to devices.

Cooperation platform, On Demand applications

Open Service Platform, Enterprise-level APP

The AR3200 routers provide a unified communication solution for enterprise customers. It uses the Open Service Platform (OSP) to interconnect with third-party IT systems. Customers, agents, third-party vendors, and manufacturers can develop unified communication systems by using the AR3200 routers.

• Integrate and customize services quickly.
• Save money and simplify management, as service integration does not require dedicated servers.
• Services synchronized with cloud-side services and local services are processed locally, which improves service quality and efficiency.

Standard MIB provided by VRP, Simplified Network and Device Management

The AR3200 routers make network and device management simple:

• Manage devices easily with the eSight network management system.
• Monitor links in real time using the NQA feature.
• Maintain peak network performance by using the NetStream feature to view traffic characteristics and statistics, as well as optimization according to usage.

Specification

**Note: Combined slots are included in the total number of slots available.
