Specifications
Mini PTZ Camera--1/4 inch super HAD color CCD
--37X optical*12X digital zoom
--550tvl(colorized)680tvl(B/W)
--0.02 lux
37X Optical Zoom High Speed Dome 550TVL Mini PTZ Camera
Stepless speed changes, auto zoom/speed matching
Pan 0.01~300 degrees/S, Tilt 0.01~200 degrees/S, Preset: 300 degrees/S (high speed IR speed dome)
Auto object track with zoom in/out and motion detection (Auto Track Model)
Timing actions for 7 days of programmable schedule
Built-in Semi-conductor heater & digital temperature sensor
PWM cooling fan vari-speed temperature control
Reserved network interface and space for network module
Pan Tilt accuracy +/- 0.1o, 256 preset positions
8 cruising tracks, each cruising track has 32 presets
4 pattern tours,10 Mins memory, 500 programmable instructions
Multi-Protocol through RS485 or coaxial cable.
8 auto scan with use-defined left and right boundaries and settable scan speed
8 Privacy Zones with defined English camera title
Auto Compatible PELCO_P, PELCO_D compatible
Guard Location: the dome will rotate back to preset position after a period of
vacant time
Alarm triggering: the alarm can trigger preset, auto scan, cruising and pattern tours functions
Soft Address Function: the use can set up the dome address without uninstall the dome
Integrated Super Speed PTZ Rotator
Delicate stepping motor, stable, sensitive and accurate
360° Pan and 90° Tilt range (auto-flip) without blind area
Stepless speed change, auto zoom/speed matching
Near / far IR Light auto matches camera zoom in/out
Built-in High Definition Day/Night Camera
with 6927P: 1/3″SONY CCD, 650TVL, 27X optical zoom (F=3.9~85.8mm), minimum illumination:0.01Lux
Auto iris, auto back light compensation
Auto/manual white balance
Auto/manual brightness control
Auto/manual focus
Multiple compatible camera brands including Sony, Samsung, LG, CNB, Sanyo
etc.
All-weather Outdoor Design
7 Inch High die-cast alloy aluminum construction
High Precision Mould with high heat conductivity
Fully enclosed isolation design for heat sink
Nanometer Dustproof, waterproof and fog-proof lens
IP66 Waterproof
3000V lightning and surge current protection
Technical Specifications
Power Supply |
DC12V+10% 50W |
Resolution |
550tvl(colorized), 680tvl(B/W) |
Manual Speed |
Pan /Tilt 0.01-300 degrees/second |
Preset Speed |
360 degree/S (high speed) / 35o/S (Vari-speed) |
Pan Angle |
360 degrees continuous pan rotation |
Tilt Angle |
90 degrees(Auto Flip) |
Presets Positions |
256 |
Preset Accuracy |
+/-0.1o |
Auto Scan |
8 auto scan tracks, user-defined left and right boundaries and scan speed |
Auto Cruising |
8 cruising tracks, each cruising tracks has 32 preset positions, user-defined dwell time |
Pattern Tour |
4 groups, each one with 10 Mins memory, 500 programmable instructions |
Guard Location |
The dome will rotate back to preset position after a period of vacant time. |
IR LED On Mode |
Manual/Auto/Timing |
Data Communication |
RS-485 |
Protocols |
Auto Compatible PELCO_P, PELCO_D |
Camera Module |
Auto Compatible SONY,LG,Samsung,CNB,HITACH,etc. |
Baud Rate |
2400/4800/9600bps |
Operating Humidity |
0~90% |
Operating Temp |
-35o~ +60oC |
