1080P HD-SDI 2 Megapixel Dome IP66 IR Outdoor PTZ Camera

Name: 1080P HD-SDI 2 Megapixel Dome IP66 IR Outdoor PTZ Camera
Brand: Joney
SKU: 128348647
Availability: InStock

Negotiable MOQ: 5 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Joney

Model Number:

HD-SD6A230-HS

Shenzhen Joney Security Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Joney

Model Number HD-SD6A230-HS

Type Digital Camera

Style Dome Camera

Sensor CCD

Technology Pan / Tilt / Zoom

Special Features Waterproof / Weatherproof

Specifications

IR Outdoor PTZ Camera
--4.3~129mm optical zoom
--ir distance up to 150m
--IP66 waterproof
--built in 7/2 alarm in/out

1080P HD-SDI 2 Megapixel Dome IP66 IR outdoor PTZ camera

Product Description

--4.3mm~129mm(30x)optical zoom(230)

--25/30fps*1080p

--25/30/50/60fps*720p

--max 240 degree/seconds pan speed, 360 degree endless pan rotation

--up to 255 presets, 5 auto scan, 8 tour, 5 pattern

--built in 7/2 alarm in/out

--IP66 water resistance

--IR distance up to 150m

Power Supply	DC12V+10% 50W
Night IR Distance	100~150meters
Manual Speed	Pan /Tilt 0.01-300 degrees/second
Preset Speed	360 degree/S (high speed) / 35o/S (Vari-speed)
Pan Angle	360 degrees continuous pan rotation
Tilt Angle	90 degrees(Auto Flip)
Presets Positions	256
Preset Accuracy	+/-0.1o
Auto Scan	8 auto scan tracks, user-defined left and right boundaries and scan speed
Auto Cruising	8 cruising tracks, each cruising tracks has 32 preset positions, user-defined dwell time
Pattern Tour	4 groups, each one with 10 Mins memory, 500 programmable instructions
Guard Location	The dome will rotate back to preset position after a period of vacant time.
IR LED On Mode	Manual/Auto/Timing
Data Communication	RS-485
Protocols	Auto Compatible PELCO_P, PELCO_D
Camera Module	Auto Compatible SONY,LG,Samsung,CNB,HITACH,etc.
Baud Rate	2400/4800/9600bps
Operating Humidity	0~90%
Operating Temp	-35o~ +60oC
