Product Construction
Alcan’s AAC cable is a concentric-lay-stranded conductor consisting of Aluminum alloy 1350-H19 wires available in both single layer and multi-layer constructions. Product Specifications
Alcan’s AAC cable meets or exceeds industry requirements per ASTM specifications B-230 and B-231.Product Features
Alcan’s All Aluminum Conductor (AAC) 1350 H-19 provides reliable performance in overhead transmission and distribution applications. AAC conductors are used in line designs that do not require the strength of ACSR type conductors while maximizing current carrying capacity.
Elastic Coefficient and Expansion Coefficient of AAC
No. of Single Wire |
Final Elastic Coefficient (Actual Value) |
Expansion Coefficient of Wire (1/0C) |
|
N/mm2 |
kgf/mm2 |
||
7 |
59000 |
6000 |
23.0×10-6 |
19 |
56000 |
5700 |
23.0×10-6 |
37 |
56000 |
5700 |
23.0×10-6 |
61 |
54000 |
5500 |
23.0×10-6 |
Packaging
1).Wrapped in rolls/coils/rings with Plastic film for small diameter cables such as building wires.
2).Treated wooden/steel-wooden drums for big diameter cables.
3).Cables are normally supplied in lengths of 100 meters,500 meters and 1000 meters according to cable size.Other length could be supplied if required.
Shipping:
1.Sample will be mailed by DHL, UPS, FEDEX, TNT, EMS etc for your selection (Freight Charge normally will be on buyer’s account).
2.The big quantity will ship by sea.
Zhengzhou Yuanda Cable Co., Ltd
Established: 1996
Factory Area: 60,000 square meters, Building area of 40000 square meters
Fixed Assets: USD 200 million
Number of Employees: more than 1,000 staffs
Annual production Capacity:100,000tons.
Certificate: ISO 9001, ISO 14001, OHSAS 18001,TUV,CE,CB,CCC etc.
Sub Factories: Rubber cable factory, conductor factory, cross-link cable factory ,cable factory, electric wire factory and special cable factory.
Zhengzhou Yuanda Cable has has a big wire & cable production base in Middle of China and we can deliver qualified cable products in very short lead time.
Our motto: “Customer Supreme, Quality First”, Zhengzhou Yuanda Cable wins customer trust as follows:
1.Quality control strictly follows ISO9001:2008 and ISO14001:2004, and all products we supplied are totally unused and use best raw materials by first-class techniques, and are carefully tested and qualified by all specified testing items.
2.Our company promises to offer best after-sale services to all customers. The service for cable fixation, installation and testing are available at customer’s request, if necessary, we can provide technicians to give detail instructions. Any problems on quality, we will repair or replace the defected products and the concerned expense or loss will be at our side.
3.Our company promises to offer cooperation and services according to the binding contract and requirements of supervision, testing for products.
Thanks for your attention to our products,we specialize in power cable for many years,with good quality and pretty competitive price.Should you have any questions,please do not hesitate to contact me.
