Professional 500kg(1200Lbs) Single Door Fail Safe Magnetic Door Lock

Name: Professional 500kg(1200Lbs) Single Door Fail Safe Magnetic Door Lock
Brand: Joney
SKU: 128315239
Availability: InStock

Negotiable MOQ: 50 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Joney

Model Number:

JYL-500

Shenzhen Joney Security Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Joney

Model Number JYL-500

Specifications

Fail Safe Magnetic Door Lock
--1200 lbs holding force
--fail safe
--with LED
--easy to operate

professional 500kg(1200Lbs) single door fail safe magnetic door lock

instruction:

A. 12VDC Input

Required power 0.5Amp(Minimum)

Connect the positive(+) lead from a 12VDC power source

Connect the ground(-) lead from a 12VDC power source

Check jumper for 12VDC operation

B.24VDC Input

Require power 0.25 Amp(minimum)

Connect the positive (+)lead from a 24 VDC power source

Connect the ground (-) lead from a 24VDC power source

Check jumper for 24VDC operation

C. Contacts

Relay dry contacts are rates 1 Amp at 24VDC for safe operation, do not exceed this ratiing.

If you require a normally open switch, connect the wires from the system to C and NO.

If you require a normally closed switch, connect the wires from the system to C and NC.

Important!

If power switch is not wired beteen DC sorce voltage and magnet, it will take a longer time to de-energize the magnet simulating residual magnetism.

Lock Size	266Lx67Wx39H(mm)
Armature plate	180Lx38Wx11H(mm)
Holding Force	500kg (1200Lbs)
Voltage	DC12V or DC24V (adjustable)
Current Draw	12V/500mA 24V/250mA
Signal Output	Dry Contact
Max Rating of Contact Current	3A
Time	0/3/6/9sec
Surface Temp.	≤+20°C
Operating Temp.	-10~+55°C(14-131F)
Suitable Humidity	0~90%(non-comdensing)
Finishes for Shell	Anodized alninum
Finishes for Magnetic	Zinc
Finishes for Armature	Zinc
Weight	2kg
Standard Packing	12pcs./carton
Suitable For	Wooden door,Glass door,Metal door,Fireproof doo
