Home > Products > packing paper making machine > 1760mm Recycled Paper Making Machine with Making Kraft Paper,Corrugated Paper for Sale
1760mm Recycled Paper Making Machine with Making Kraft Paper,Corrugated Paper for Sale
- 0 per Month
- Tianjin Qingdao Shanghai Ningbo
- T/T Credit Card
- 3200mm Double Cylinder Double Wire Kraft Paper Making Machine
- Waste Paper Recycling Kraft Paper Making Machine Price
- 4800/500-380TPD Kraft Liner Paper Machine With High-strength
- Reliable Quality Waste Corrugated Paper Machine
- Most Popular Products China,Corrugating Machinery,Corrugated Paper Machinery
- 3200mm Three-wire Fourdrinier High Performance Paperboard Making Machine
Product Details
Condition: | New | Product Type: | Other, Kraft Paper | Processing Type: | Other, paper making machine |
Place of Origin: | Henan, China | Brand Name: | Pingan | Model Number: | 1760mm |
Voltage: | can be specified | Power(W): | 380V | Dimension(L*W*H): | According to each type |
Weight: | According to each type | Certification: | Other, ISO9001:2008 | Warranty: | 12 months |
After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
Standard Export Packing
Product Description
1760mm Recycled Paper Making Machine with Making Kraft Paper,Corrugated Paper for Sale
Skype:hwasong03
Technical parameter:
1. Output paper: kraft paper, fluting paper, corrugated paper
2. Raw material:recycled paper, wood pulp, wheat straw etc
3. Capacity: 10-15 T/D
4. Output paper weight: 100-250g/m2
5. Net paper width: 1760mm
6. Wire width: 2150mm
7. Rail gauge: 2600mm
8.Working Speed: 80-150m/min
9.Drive way: AC frequency conversion speed,section drive
The main equipment :
1.the mesh part : φ1500mm×2150mm netcage two sets , φ400mm×2300mm couch three sets (including four sets turning roll ), the shore hardness is 380±2 , and the gas pressure device , equipment with two sets press net-wire modling machine .
part : the main press : φ750mm×2300mm stone roll one set , φ700mm×2300mm rubber roll one set, the prepress part : φ650mm×2300mm stone roll two sets , φ600mm×2300mm rubber roll two sets , shore hardness is 900±2,and gas pressure device , equip with vacuum section device .
3.the dryer part : φ2500mm×2150mm dryer cylinder two sets , φ1300mm×2150mm dryer cylinder sixteen sets , the arrange is : (one +eight +one + sizingmachine +eight ), φ600mm×2300mm rubber roll two sets , shore hardness is 900±2, and the gas pressure device , the group cylinder part equip with up and down dyer wire device , the big dryer cylinder equip with the down dryer wire device .
4. glue machine : 1760mm two rolls sizing machine .
5.calendarand winding part : 1760mm three roll calendar and 1760mm mesh type winding
machine .
6.drives and control system : AC inventer adj. and the gear drives by step , and the full digital
sealed ring control system
Factory information:
Raw Material:
Production Folw:
Certification:
1. We will send technicians to installand test the machine for you.
2. We will train skilled workers for you.
3. We will supply best after-sale service.
We have more than 30 years manufacturing experience of different kinds of paper machines in China. We strictly manufacture and manage according to IOS9001:2000 System and match all the CE standard or stricter standard. Our paper machine is running well in more than 20 countries. We are gold supplier on alibaba. Our guarantee period is 1 year. If there are any quality problems, We will help you at any time.
FAQ: | ||||||||
1. What kind of paper machine your factory produce? | ||||||||
We produce different kinds of paper machine. such as: | ||||||||
a.Toilet Paper Machine which can produce toilet paper, tissue paper, napkin paper, handkerchief paper, towel paper and kitchen using paper etc. | ||||||||
b.Culture paper machine which can produce A4 paper, notebook paper, copy paper, writing paper, printing paper and newsprinting paper etc. | ||||||||
c.Packing paper machine which can produce kraft paper, fluting paper, corrugated paper, kraft liner paper, carton box paper and packing paper etc | ||||||||
d.Coating paper machine which can produce coating paper, carbonless copy paper and thermal paper etc. | ||||||||
2. Can you make paper mill design for us? | ||||||||
Yes, we have professional team with rich experience of paper mill design by CAD software. Our engineer will design paper machine suitable for your factory. You only need to tell us your open land dimension, we will make your future paper mill design. | ||||||||
3. How about your machine’s quality, we worry about the quality? | ||||||||
We have more than 30 years manufacturing experience of different kinds of paper machines in China. We strictly manufacture and manage according to IOS9001:2000 System and match all the CE standard or stricter standard. Our paper machine is running well in more than 20 countries. We are gold supplier on alibaba. Our guarantee period is 1 year. If there are any quality problems, We will help you at any time. | ||||||||
4. What should I have to know if I want to get the quotation? | ||||||||
1.What kind of paper you want to produce(main important) | ||||||||
2.What kind of raw material you will use(main important) | ||||||||
3.The capacity you want produce per day(main important) | ||||||||
4.The paper weight you require. | ||||||||
5.The paper width you require. | ||||||||
5. Why your price is so high, is there any discount? | ||||||||
The price is matched with the quality of our machine. We can give you some discount if you want to buy our machine sincerely and earnestly. However, if you want a low quality paper machine. I tell you, we don’t produce. Our company’principle is client first, reputation premier. | ||||||||
6.Could your engineer can teach and train our workers and stay in our factory for long time? | ||||||||
Yes, we have very large engineer installation team. They can train and teach your workers to operate paper machine, but you should pay them salary. | ||||||||
7.How long will it take to get the quotation? | ||||||||
We usually give reply within 24hours after getting your inquiry. If you are urgent to get the quotation, please tell us by email, then we can reply you as the first priority. | ||||||||
8.How we visit your fatory and what will be the proedure? | ||||||||
Our company located in Zhengzhou city, henan province, if you take plane, it will need about 2 hours from Guangzhou city, 1.5 hours from Shanghai city and 1 hour from Beijing city. We will pick you up from Zhengzhou airport or the train station. We will take you to see our machine running in our chinese clients' paper mill. Welcome you and your team to visit us at any time! |
Company Profile
Qinyang City Pingan Light Industrial Machinery Co., Ltd. is a large- scale enterprise specialized in papermaking machinery field, covering the scientific research, design, manufacturing, installation and commissioning. Established in 1968, our company covers an area of 57000m2, in which the occupation of manufacturing workshop is 16000m2 and the occupation of office and living rooms is 3500m2. We have fixed assets of 5 million USD and eight large-scale production workshops. The annual gross product of our company is 110 million dollars under the concerted effort of 160 staff on duty. In 2004, we passed the international quality authentication of ISO9001 system.
The main products of our company are multi-series cylinder mould paper machine, short fourdrinier paper machine, fourdrinier paper machine and multi-layer fourdrinier paper machine based on the paper width of 787mm, 1092mm, 1575mm, 1760mm, 1880mm, 2100mm, 2400mm, 2640mm, 2800mm, 3200mm, 3600mm, 3800mm, 4600mm. And we are also devoted to the manufacturing of pulp making equipment and paper converting equipment.
Since the reform and opening-up policy of our state, we have exported our machines and equipment in due succession to many foreign countries like Indonesia, UZ, Russia, Kyrgyzstan, KZ, Turkmenistan, Surinam, Syria, Mongolia, Mali, Uganda and Venezuela so forth, and also send to all parts of our country. The high quality of our products and our after-sales service bring us the terrific reputation and high praise from the clients at home and abroad!
Contact Us
- Qinyang City Pingan Light Industrial Machinery Co., Ltd.
- Contact nameCHENG WEI
- Phone0086-0371-86636319
- AddressLizhang Village, Wangqu Township, Qinyang
