Hoozoe Outdoor P10--W

Hoozoe Outdoor P10--W thumbnail-1
Hoozoe Outdoor P10--W photo-1
Negotiable MOQ: 50 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Hoozoe
Model Number:
Hoozoe-P10 -W
Contact Supplier Request Quote Chat Now
Fujian Hoozoe Optoelectronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Fob Xiamen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name Hoozoe
Model Number Hoozoe-P10 -W
Usage Outdoor
Tube Chip Color Other, Red, White
Display Function Other, Graphics, Graphics ,Text, Message
Pixels 10mm
Screen Dimension 320mm*160mm

Specifications

1.High Stability, Power Saving
2.CE,ROHS, ETL,CE,RoHS,TUV,FCC-A,CCC Certified
3. High Cost Performance

Hoozoe Outdoor P10--W
Product Description





Shipping Cost Problem:

 If it is because the shipping cost too high that cause your hesitation to order, please contact me on Alibaba TradeManager or leave a message.

for expample:

     "Scott, I want to order this product, 20pcs to Chennai city, India. Zipcode: 11111. Please check the best shipping way and cost for me."
     Once I catch your message, I will check the best shipping information from the agent, and will change the price.
     Or if you have any other requirements, welcome your message.
     Best regards to you and your family.

  • Discount package
  • Buy 2 cartons, get 1 power supplier free;
  •  Buy 4 cartons, get 2 power suppliers free;
  • Buy 6 cartons, get 2 power suppliers and 1 control card free;
  • Buy 8 cartons, get 3 power suppliers and 1 control card free;
  • Buy 10 cartons, get 3 power suppliers and 2 control card free;
  •  ( PS: 60pcs/carton)

Production Paramater

 P10 Single Red Outdoor Led Module



  The technical  parameter of  P10 Display Module
Number Item P10 Single White Module
1 Pixel pitch 10mm
2 Size of  module  (wxh) 320mm X160  mm
3 Resolution of module (wxh) 32 dots X16 dots
4 Density of pixel 10,000dots/m²
5 Pixel configuration 1R or 1G or 1B or 1W
6 Red wavelength 625±2nm
7 Green wavelength 525±2nm
8 Blue wavelength 470±2nm
9 Colors W
10 Best viewing distance 10-100m
11 Horizontal viewing angle 120°
12 power consumption 200w/m²
13 Brightness >3500cd /m2
14 Gray scale 16bits per color
15 Color temperature 5500k
16 Control method Synchronization & Asynchronization
17 Driving method 1/4  scanning
18 Frame frequency 60Hz
19 Refresh frequency >300Hz
20 Working voltage AC220V/110V±10%
21 IP grade IP65
22 Working temperature -20°C~80°C
23 MTBF >10000 hours
24 Life span >100,000 hours
25 Defects rate. ≤0.00001(Led display line standard<0.0001)



Note: the specification for refrence only, we are improving our products all the time.



Reference PicturesHoozoe Outdoor P10--W
 Hoozoe Outdoor P10--W



Packing Method
    • 40 pcs/ Carton
    • Carton Size: 50 cm x 33cm x35cm
    • Weight: 25.7Kg
Hoozoe Outdoor P10--W

Hoozoe Outdoor P10--W

Advantage of Factory

1. 53000 square meters manufacturing base , More than 1200 employees ;
2. Standardized management and production :
3. 20000pcs modules per day and 65000 square meters display screen per month
4. With integrated R&D, manufacturing and service system , from LED application solutions to after-sale service
5. Certificates : ISO9001-2008,3C, CE, UL etc.

Advantage of Products
1.Steady performance and low death rate of light
2. Own designing team for new products development
3. Independent design of PCB board circuit : tidy electronic line and Uniform color
4. New pattern vacuum package

Remarks:

1. Quotation valid time: 20 days after receive 50% deposit;

2. Payment method: T/T 50% down payment before production, T/T 50% balance before delivery;

3. Production lead time: 15 days calculated from the date we received T/T 50% down payment;

4. Quality Warranty Period: two years from delivery date;



Packaging Details

Unit Type: piece
Package Weight:0. 700kg (1.54lb.)
Package Size: 33cm x 17cm x 5cm (12.99in x 6.69in x 1.97in)
