Hoozoe LED Full Color Module P10

Name: Hoozoe LED Full Color Module P10
Brand: Hoozoe
Price: Negotiable

FOB Price

Negotiable / Piece

10 Pieces(Min.Order)

Product Details

Place of Origin:	Fujian, China	Brand Name:	Hoozoe	Model Number:	Hoozoe-Outdoor-DIP-P10-RGB
Usage:	Outdoor	Tube Chip Color:	Full Color	Display Function:	Other, Video,Message,Picture,Text
Pixels:	10mm	Screen Dimension:	960*960mm

1.High Stability, Power Saving
2.CE,ROHS, ETL,CE,RoHS,TUV,FCC-A,CCC Certified
3. High Cost Performance

Product Description

P10 Full Color Outdoor Module
Item	Unit	Parameter
Pixel Pitch	mm	10.00
Pixel Density	dots/sqm	10,000
Resolution of Module	dots	32×16
Module Size	mm	320×160
HUB		75A
Led Package	DIP Oval 346 lamp
Pixel Configuration	1R1G1B
Chip Brand of LEDs	Epistar
Module Weight	kgs/pc	0.46
Brightness (White Balance)	nits(cd/sq.m)	7,500
Red Wavelength	nm	620-625
Green Wavelength	nm	520-525
Blue Wavelength	nm	470-475
Scan Mode	1/4 Scan
View Distance	M	5~100
Best View Distance	M	12.5~33
Viewing Angle-Horizontal	deg.	110
Viewing Angle-Vertical	deg.	60
Module Maximum Power	W	33.4
Max. Power Consumption	W/sq.m	1,302
Avg. Power Consumption	W/sq.m	390
Working Voltage	40A 5V
Power Supply	AC 110/220V
Waterproof Grade	IP65
Refresh Rate	Hz/S	3,000
Frame Rate	Hz/S	≥ 60
Gray Scale	4096 grades gray
Display Color	256256256
Display Function	Text,news,advertising,flash,animation
Input Signal	RF,S-Video,RGB,RGBHV,YUV,YC,SDI,HD-SDI,DVI,UXGA,COMPOSITION,etc.
Luminance Degradation	Less than 5% after 1000 hours Ageing test, testing current 30mA, under normal temperature 25℃.
Defective Dot Rate		<0.0001
Life Span	hours	100,000
MTBF	hours	>10,000
Storage Temperature	℃	-35 -- +80
Working Temperature	℃	-20 -- +80
Working Humidity	10%-90%RH
Control System	Synchronization or Asynchronization
Quality Certificate	ETL,CE,RoHS,TUV,FCC class A,ISO9001:2008
Warrenty	2 Years
Working Environment	Outdoor
Other Fertures	LED&ICs in Departed PCB
Note: The above parameter is just for reference. Changes can be made according to customers' requirements.

Products Pictures

Products Advantage:

1. Good Frame---resist high tempreture and low tempreture

2. Lamp Chip: ALL EPISTAR lamp and 9MIL chip

3. The organized design ---muchtidy PCB , balanced modules light

4. One more capacitors ---- more steady voltage

5. The water-proof groove----great drainage and waterproof

6. Pin header with protection--firmly connection between data cables and modules

Packaging & Shipping

Our Services

(1). Product Quality : For LED Modules , 24 hours Aging test before shippment;

For LED Display, 72 hours Aging test before shippment

which will avoid some problems and make customers satisfied with the quality of our led products.

(2). After Sale Service : 1 year warranty ;

Complete instruction for led screen installation

Professional technical team for remote control maintenance .

Fujian Hoozoe Optoelectronic Co., Ltd.: Contact nameModern Dai; Phone0086-595-28765512; AddressNo.153, Chongxiang Rd., Qingmeng Zone Quanzhou,Fujian
