Help CenterDie Casting Series -High Definition Portable Led Billboard
Related Products
-
Die Casting Series -High Definition Portable Led Billboard in MelbourneUS$ 1,400 - 1,800MOQ: 5 Square Meters -
Die Casting Series -High Definition Innovative New ProductsUS$ 1,400 - 1,800MOQ: 5 Square Meters
-
Die Casting Series -High Definition Indoor VideoUS$ 1,400 - 1,800MOQ: 5 Square Meters
-
Die Casting Series -High Definition Led Public DisplayUS$ 1,400 - 1,800MOQ: 5 Square Meters
-
Die Casting Series -3D Led Commercial SignUS$ 1,400 - 1,800MOQ: 5 Square Meters
Specifications
1.High Stability, Power Saving2. Convenient assemble and save space
3. High Cost Performance
4. Ultrathin
5. CE, 3C etc.
Technical Parameters
| P5 Full Color SMD3528 Indoor Module | ||
| Item | Unit | Parameter |
| Pixel Pitch | mm | 5 |
| Resolution of Module | dots | 64×32 |
| Module Size | mm | 320×160 |
| Module Weight | kg | 0.4 |
| Pixel Configuration | SMD3528 1R1G1B | |
| Chip Brand of LEDs | Epistar | |
| Pixel Density | dots/sqm | 40,000 |
| Brightness (White Balance) | nits(cd/sq.m) | 2000 |
| Red Wavelength | nm | 620-625 |
| Green Wavelength | nm | 520-525 |
| Blue Wavelength | nm | 470-475 |
| Scan Mode | 1/16 Scan | |
| Viewing Distance | M | 3--35 |
| Best View Distance | M | 5--15 |
| Viewing Angle-Horizontal | deg. | 120 |
| Viewing Angle-Vertical | deg. | 120 |
| Module Maximum Power | W | 25 |
| Max. Power Consumption | W/sq.m | 1,000 |
| Avg. Power Consumption | W/sq.m | 300 |
| Working Voltage | 5V 40A | |
| Power Supply | AC 110/220V | |
| Refresh Rate | Hz/S | 3,000 |
| Frame Rate | Hz/S | ≥ 60 |
| Gray Scale | 4096 grades gray | |
| Display Color | 256*256*256 | |
| Display Function | Text,news,advertising,flash,animation | |
| Input Signal | RF,S-Video,RGB,RGBHV,YUV,YC,SDI,HD-SDI,DVI,UXGA,COMPOSITION,etc. | |
| Luminance Degradation | Less than 5% after 1000 hours Ageing test, testing current 30mA, under normal temperature 25°C. | |
| Defective Dot Rate | <0.0001 | |
| Life Span | hours | 100,000 |
| MTBF | hours | >5,000 |
| Storage Temperature | °C | 45 |
| Working Temperature | °C | -20 -- +60 |
| Working Humidity | 10-90%RH | |
| Control System | Synchronization or Asynchronization | |
| Quality Certificate | ETL,CE,RoHS,TUV,FCC class A,ISO9001:2008 | |
Our Case
Reference Pictures
Connection Picture
A: Wooden Case
B: Air-line Case
- 2 Years Warranty;
- Professional technical team
- Providing Our Local Service from our Foreign Distributor;
Advantage of Factory
1. 53000 square meters manufacturing base , More than 1200 employees ;
2. Standardized management and production :
3. 20000pcs modules per day and 65000 square meters display screen per month
4. With integrated R&D, manufacturing and service system , from LED application solutions to after-sale service
5. Certificates : ISO9001-2008,3C, CE, UL etc.
6. Accept OEM and ODM
7. Quick delivery time : 10 days after receiving payment .
Advantage of Products
1.Steady performance and low death rate of light
2. Own designing team for new products development
3. Independent design of PCB board circuit : tidy electronic line and Uniform color
4. New pattern vacuum package
What is the life time for a LED screen?
The life time for the LED screen is basically over 100,000 hours, but it depends how the client is taking care of his LED screen and how it is used. When a LED Screens´ life time gets to 100,000 hours, it means that the brightness of the LED lamps of the LED screen is about 50% off as compared to the original brightness depending on several factors that will enlarge a LED screen´s life time or reach 100,000 hours.
What is the led chip packing?
546 oval lamp/346 oval lamp/SMD 3528/8X8 Array module
How to protect power supply?
Electrical peaks can put more force on the electrical components which will decrease life time .
it is wise to install a protection (voltage stabilizer) that can control the peaks.
How to main the led screen?
The soldering of the LED chips can dry out and break which require changing often components such as LED modules and receiving card .
What is the return policy?
If the module died exceed 1%,we can resend you the new one.
