Specifications
1.Super Steel Structure Design,the body is more stable and reliable.2.Full use of PLC intelligent control
Full-automatic planting grass brick making machine
Description:
New semi-closed hopper,inner machine has straight line reciprocating mesh,put material into block machine molds
quickly and uniform.Maximize the use of effective vibration, balance-of-will spread to Die me ministries,greater
density and to improve product life-me.
Features:
1.ZFZJ-8-15
2.Super Steel Structure Design,the body is more stable and reliable.
3.Full use of PLC intelligent control and man-machine interface dialogue system.Easy random signal analysis, fault diagnosis and various parameter settings to
ensure the best running machine.
4.Brick machine without burning,Efficient, super excitation system design, the use of computer-controlled hydraulic system flow pressure to achieve vertical synchronous vibration, frequency, brakes, and
double-end composite output, balanced efficiently vibration excitation force to the mold box ministries,
greatly improved product density and mold box of life.
5.Feeding System:Take a semi-closed mesh rotation forced feeding,feeding evenly and quickly, to ensure consistent product strength.
6.Fitted with special brick yards board machines, can easily achieve high production, automated production, saving a lot of manpower, maintenance yard and liquidity of investment.
Specification:
Model |
ZFZJ-8-15 |
Main machine size |
6100*2800*2660 mm |
Forming size |
900*800 mm |
Forming height |
32-200 mm |
Forming time |
11-18 s |
Tray size |
950*850 mm |
Main machine weight |
13 T |
Main motor |
37.5kw |
Capacity list:
Product name |
Specification |
PCS/Tray |
PCS/Shift |
PCS/Year |
Remarks |
Standard Brick |
240*115*53mm |
42 |
76,800 |
46,080.000 |
8Hrs/day 2 shift |
Hollow block |
390*190*190mm |
8 |
17,280 |
10,368.000 |
|
Holes Brick |
240*115*90mm |
20 |
38,400 |
23,040.000 |
|
Pathway Brick |
200*100*60mm |
22 |
42,240 |
251,420.000 |
Pictures:
End products:
Contact way:
