Large Hole Diameter HTK-800A-6 Hydraulic Pile Hole Drilling Rig

Large Hole Diameter HTK-800A-6 Hydraulic Pile Hole Drilling Rig thumbnail-1
Large Hole Diameter HTK-800A-6 Hydraulic Pile Hole Drilling Rig photo-1
US$ 5,200 - 5,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Rotary Drilling Rig
Power Type:
Diesel
Contact Supplier Request Quote Chat Now
Sanhe Hargrand Drilling Tools Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Rotary Drilling Rig
Power Type Diesel
Place of Origin Beijing, China
Brand Name HARGRAND
Model Number HTK-800A-6
Usage Other, geotechnical investigation and surveying
Voltage 220v
Power(W) 12.1kw
Dimension(L*W*H) 6500*2200*2880
Weight 9200
Certification ISO-9001
Warranty 6months
After-sales Service Provided Engineers available to service machinery overseas

HTK-800A-6 pile hole drilling rig  Introduction:

HTK800A all hydraulic pile hole drilling rig is the foundation of core drilling rig, well drilling rig, drilling rig, the unique dual power head design, which can be used in electric power, highway, railway, bridge pile hole construction, with tied down hole hammer, which can be used in large diameter pile construction, and the construction process has been obtained national patent (patent number 201420766541). The drilling machine will be used in the field of pile hole engineering with its multifunctional and high performance price ratio.

HTK-800A-6 type:    track-mounted rig,    trailer mounted rig



Drill Rigs Features:


1.easy operation

2.lightweight to move

3.reasonable price

4.good service

Technological Data of  HTK-800A-6 pile hole drilling rig:



Diesel engine



Model cummins                                                                6BTA5.9-C150



Power                                                                                   110KW



Rotate speed                                                                        2200RPM



Motor



Power                                                                                   75KW



Rotate speed                                                                       1450RPM



Rotate power hend



Rotate speed                                                                      0-120RPM



Max. torque                                                                        16000KN



Max. pullback force                                                             150KN



Max. feed force                                                                   150KN



Mast



Height                                                                                  4.5m



Angle                                                                                   0°-90°



Stroke                                                                                  3.5m



RC drilling



Max. diameter                                                                  1000mm



Depth                                                                                    30m



Rock with water and air composite DTH



Max. diameter                                                                            800mm



Depth                                                                                          30m



Air consumption                                                                          31/24 m³ /Kg

Jet drilling



Max. diameter                                                                        400-2000mm



Depth                                                                                           50m



CFG drilling



Max. diameter                                                                             400mm



Depth                                                                                            3.5m



Transport parameters



Weight                                                                                      9200kg



Overall dimensions                                                            6500*2200*2880



Drill rigs Factory:





HTK-800A-6 drill rig  ware house:









  HTK-800A-6 pile hole drill rig  customer:



Quality Drill rigs Manufacturer In China  -FAQ



Payment terms:100% by TT ,



Delivery time:10 days after deposit



Supply ability:1000 pcs per month.







If you want to get more information,please contact me.



Name:Eric Qin



Skype id: hargrand163
