HZ-200YY soil testing drilling rig Introduction:
HZ-200YY soil testing drilling rig is suited for the applications of general exploration and investigation, geophysical prospecting, road and construction survey, blast holes and other drilling operations.
HZ-200YY type: track-mounted rig, trailer mounted rig
Drill Rigs Features:
rotary drilling rig
1.easy operation
2.lightweight to move
3.reasonable price
4.good service
Technological Data of HZ-200YY soil testing drilling rig:
Unity machine parameter
Drilling depth 200m
Maximum open hole caliber 300mm
End hole caliber 75mm
Drill rod caliber 60mm
Drilling angle 90~75
Drill weight (No include power) 975kg
Triangle conveyer belt B950 x 4 B1700 x 3
The main machine moving distance 300m
Power diesel engine 22HP
electric motor 15kw
Spindle
spindle speed 64, 128, 287, 557r/min
Spindle stroke 450mm
Hoist
Max.single line hoisting capacity 2400kg
Single line lifting speed 0.41,0.82,1.64m/s
Wirerope caliber 13mm
Wirerope length 35mm
Reel diameter 140mm
Hug floodgate caliber 260mm
Hug floodgate belt width 70mm
Mud pump
Type Horizontal single urn twin-action
Displacement diesle engine 170L/min
electric motor 150L/min
Maximum pressure 3Mpa
Work pressure 1.5Mpa
Inlet pipe caliber 40mm
Outlet pipe caliber 30mm
Triangle conveyer belt B1728mm
Hydraulic oil pump
Type CNT-F-314
Triangle conveyer belt B1100 x 1
Drill rigs Factory:
HZ-200YY soil testing drill rig ware house:
HZ-200YY water well drill rig customer:
Quality Drill rigs Manufacturer In China -FAQ
Payment terms:100% by TT ,
Delivery time:10 days after deposit
If you want to get more information,please contact me.
Name:Eric Qin
Skype id: hargrand163
