Wood Cnc Router Made in China SK1325 OEM Available

Name: Wood Cnc Router Made in China SK1325 OEM Available
Brand: SUKE
SKU: 128031319
Availability: InStock

US$ 5,000 - 8,000 MOQ: 1 Set

Key Specifications

Condition:

New

CNC or Not:

CNC

Place of Origin:

Shandong, China

Jinan Suke Science & Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

CNC or Not CNC

Place of Origin Shandong, China

Brand Name SUKE

Model Number SK1325-III

Specifications

Wood cnc router made in china SK1325 OEM available
1.CE certificate
2.4.5kw 24000rpm water cooling spindle
3.stepper motor

Wood cnc router made in china SK1325 OEM available
Feature

1. Square tube lathe bed , stable , not deformation with heavy-duty.

2. Vaccum table and vacuum pump , working without clamps to improve the work efficiency.

3.X,Y,Z axis are square orbit Hiwin , ensuring the high precision.

4.X,Y rack and gear transmission movement, Z axis with german ball screw 30mm

5. Y axis with two stepper motors, improve the working speed.

6. 4.5kw water cooling spindle with 24000rpm rotation speed, good refrigeration, high stable with low fault.

7. DSP control system , DSP handle operation

8. MA860 Leashine driving system

9. Automatic oiling system, machine working with low noise and smoothly, extend the using time.

10.Standard gantry height: 200mm (customize is avaiable )

Technical Data

Model	SK1325-III
Machine structure	Square tube lathe bed, vacuum table
Working holding	By vacuum
X Y movement	Rack and gear
Z movement	Ball screw/ German
Guide/rail	Round rail/Taiwan HIWIN
Precision (mm)	0.07
Positioning accuracy (mm)	0.02
Repeatability (mm)	0.02
Idling speed (mm/min)	25000
Working speed (mm/min)	15000
spindle	4.5kw Water cooling (0-24000rpm)
Available tools (mm)	Φ3.175~Φ12.7
Drive system	Stepper motors
Working voltage	AC380V±30V, 50HZ
Command code	*G code (.nc,.mmg, 8.u00, etc.),.eng**
Control system	DSP system
Compatible software	Compatible with any software generating G code file in window 98/XP/7
Optional parts	1. Specified power, air-cooling (0-18000 rpm) 2. Automatic tool changer 3. Servo motors 4. Tool cooling system with sink 5. Rotary device
