The machine equipped with Siemens control system. Electrical components such PLC, motor, energy saving inverter, contactor and low voltage electrical parts are all Siemens. The machine has an excellence performance with Siemens control system.
Special designed mold clamping system, stable and reliable. Higher lock pressure, fast closing and opening.
Thicker mold clamping platen, solid stiffener provide super strength to the platen. No deformation during high locking pressure. Ensure the perfect shape of products.
Advanced IKV screw is using. Enforced feeding ensure the higher plasticizing capacity and energy saving. Efficiency cooling system and heater covers make the maintenance simple and safe.
Innovative 4 layers and 3 layers die head design. The bellwether of Multi-layer super size blow molding machine manufacturer in China.
BLOW MOLDING ADVANTAGES:
* Material, blow molded tank are using HDPE material which is strongger than LLDPE for rotational tanks.
* Weight, weight for 1000L rotational molded tanks is 22 kg, but for blow molded, the weight of 1000L can be 18kg which is in less weight but more stronger.
* Output is higher, The output on blow molding machine is 12pcs/h, but on rotational molding it is 2-3 pieces per hour.
* Blow molding is using eletricity, environment is neat and clean.
* Labor saving, blow molding machine is fully automatic.
Commodity | Output | Unit | Weight | Unit |
500 L Mould | 17 | PC/H | 9 | KG |
750 L Mould | 15 | PC/H | 12-13 | KG |
1000 L Mould | 12 | PC/H | 18 | KG |
TRAINNING
The Buyer could dispatch their operators to the Seller’s factory for training, including machine operation, maintenance & simple repairs;
Or against the requests of the Buyer, the Seller’s technician could train the Buyer’s operators in the Buyer’s factory in the periods of installing & adjusting;
The training is free of charge;
INSTALLATION & ADJUSTMENT
The Seller could dispatch an engineer against the requests of the Buyer to install and adjust the machines for one week in the Buyer’s factory.
The Buyer should make a reservation in advance before delivery of the machines;
The Buyer should pay for the engineer’s visa application cost, round air tickets, food & board before his departure;
GUARANTEE
The guarantee time is one year after the machines normally works in the Buyer’s factory, if only the problem is cause due to quality control or any reason by the Seller. We will supply replaced parts free of charge and our engineers will guide you how to solve the problems.
Any problem caused due to irregular operation or incorrect maintenance by the Buyer won’t be listed in guarantee coverage.
