Chiller Used for Blow Molding Machine

Name: Chiller Used for Blow Molding Machine
Brand: YANKANG
SKU: 128029417

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Type:

Water-Cooled

Place of Origin:

Shandong, China

Brand Name:

YANKANG

Qingdao Yankang Plastic Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO CHINA

Delivery Detail:

Delivery time depends on order quantity.

Type Water-Cooled

Place of Origin Shandong, China

Brand Name YANKANG

Model Number HTS-60A/HTS-80A

Warranty one year

product function

Chiller: the mold need to foced cooling to improved the productivity of the products.

In the process of rapid prototyping,mold need cooling as soon as possible in order

to speed up finalize the design of products,so as to improve the yield and quality

of products.

specification

Model[HTS-***]			60A	80A
Nominal Cooling Capacity		Kcal/h	128484	189760
		KW	149.4	220.6
Max Power Consumption		KW	59.95	83.05
Power Source			3PH 380V/50HZ
Refrigerant	Type		R22
	Charge	KG	42		57
	Control		Thermal expansion valve
Compressor	Type		Semi-hermetic screw
	Motor power	KW	50.2	70.5
	Start mode		Y-
	Capacity control	%	0-25-50-75-100
Condenser	Type		finned copper tube + low noise axial fan
Fan	Type		Big volume & low noise axil fan
	Fan Motor	KW	1.0×6	1.1×8
	Air Volume	m3/h	60000	80000
Evaporator	Type		Shell and tube
	Coolant Flow	m3/h	25.7	40.5
	Pipe connection	Inch	3	4
Pump	Power	KW	3.75	3.75
	Head	m	20	20
Unit Protection Modules			Compressor Overheating, Motor Overload, High&Low Pressure, Chilled Water Over Temperature, Tank Water Level
Dimension	Length	mm	2650	2950
	Width	mm	1800	1950
	Height	mm	1930	2200
Weight		KG	1900	2350
