AUTOMATIC BOTTLES CARTONS MACHINES
US$ 1 - 100,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage, Commodity, Food, Medical
Packaging Type:
Bottles, Other, Bottles, Ointment
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
ALU PVC BLISTER PACKING MACHINEUS$ 1 - 100,000MOQ: 1 Set -
HIGH SPEED BLISTER PACKING MACHINE FOR ALU-PVC OR ALU-ALU BLISTERUS$ 1 - 100,000MOQ: 1 Set
-
ALU-PLASTIC FULLY AUTOMATIC BLISTER PACKAGING MACHINESUS$ 1 - 100,000MOQ: 1 Set
-
DPP-250A Automatic Alu PVC Blister Packaging MachineUS$ 1 - 100,000MOQ: 1 Set
-
SMALL ALU-PVC AUTOMATIC BLISTER PACKING MACHINESUS$ 1 - 100,000MOQ: 1 Set
Condition
New
Application
Beverage, Commodity, Food, Medical
Packaging Type
Bottles, Other, Bottles, Ointment
Packaging Material
Paper
Automatic Grade
Automatic
Driven Type
Electric
Voltage
220V/380V
Power
0.75 KW
Place of Origin
Jiangsu, China
Brand Name
HUALE MACHINERY
Model Number
DXH-120WP
Weight
1600KG
Dimension(L*W*H)
4200*1200*1600mm
Certification
CE, ISO
After-sales Service Provided
Engineers available to service machinery overseas
AUTOMATIC BOTTLES CARTONS MACHINES
Main technical parameters
Cartoning speed |
50-100 Carton/min |
|
Carton |
Request |
250-350g/m2(addcording to carton size) |
Specification |
(50-200)×(20-80)×(14-45)mm |
|
Leaflet |
Request |
55-65g/m2 |
Folded Leaflet Specification(1-4) Fold |
(80-240)×(90-190)mm (L×W) |
|
Compressed air |
Pressure |
≥0.5Mpa |
Consumption |
120-160L/min |
|
Motor Power |
220V 50HZ 0.75kw |
|
Dimension |
4200×1200×1600mm (L×W×H) |
|
Net weight |
1600kg |
|
Performance and characteristic
- It adopts PLC automatic control and touch screen operating system with speed adjusting by inverter.
- Main transmission system gets overloading protecting device
- Automatic trouble shooting, alarming and production counting functions are all programmed in the machine.
- The machine gets stable performance, easy to change different sizes of products
- Detection and Rejection of cartons which gets no object fed or leaflet fed.
- Rotary feeder with speed adjusting motor for feeding different sizes of tubes or bottles.
Applications
The machine is suitable for packing different sizes and specifics of tubes or similar objects with automatic leaflet folding inserting, carton opening, object cartoning, batch number embossing and cartooning sealing (hot glue sealing is an optional for the machine). It adopts PLC control with touch screen operation with all working stations equipped electronic sensor for running status monitoring.
