KingCCTV Newest All in One 4CH 1080P LCD DVR 21.5 Inch Touch Screen XVR
US$ 218 - 229
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Hyking
Model Number:
TS2104MT
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
AHD NVR DVR 3 in 1 AHD 21.5" LCD Touch Screen 21.5'' 1080P LED Monitor CCTV Multi-touch XVRUS$ 242 - 255MOQ: 1 Piece -
AHD DVR 1080P 21.5 Inch Touch Screen XVR 3 In1 4 Channel LCD DVRUS$ 218 - 229MOQ: 1 Piece
-
New Products 32Ch 5MP 3MP 1080P Onvif P2p Network Dvr,H.265 NVRUS$ 36 - 74MOQ: 1 Piece
-
Camera Security System IP Camera Video 16ch PoE NVR Recorder System Kit 16 CH PoE NVR,Support Max to 16TBUS$ 36 - 74MOQ: 1 Piece
-
25CH Onvif CCTV NVR CCTV Kit Systems IP Camera NVRUS$ 36 - 74MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Hyking
Model Number
TS2104MT
KingCCTV Newest All in one 4CH 1080P LCD DVR 21.5 Inch Touch Screen XVR
W What is the Feature of our Products?
>21.5'' 1080P LED monitor, Multi-touch, Electronic zoom, Easy to operate
>AHD DVR NVR 3 in 1
>Multi-mode switch:
AHD: 4CH*720P(compatible with 960H analog);
AHD+IP: 2CH*720P+2CH*IPC1080P; IP: 4CH*1080P; 9CH*1080P;
W What is the Specifications of our products?
| TS2104MT | |
| Video/Audio input | |
| Video compression | H.264 |
| Analog video input | 4PCS BNC Port(Level: 1.0Vp-p, impedance : 75Ω) |
| Audio compression | ADPCM |
| Audio input | 4PCS RCA Port(Level : 2.0Vp-p, impedance : 1kΩ) |
| Two-way audio input | 1PCS RCA Port( line level , impedance : 1kΩ) |
| Video/Audio output | |
| Multi-mode switch | AHD: 4CH*720P(compatible with 960H analog); AHD+IP: 2CH*720P+2CH*IPC1080P; IP: 4CH*1080P; 9CH*1080P; |
| HDMI/VGA output | 800x600,1024x768,1280x1024,1440x900,720P,1080P |
| CVBS output | No |
| Encoding resolution | CIF/D1/960H/720P/960P/1080P |
| Frame rate | NTSC:1~30FPS/S;PAL:1~25FPS/S |
| Video bit rate | 256kps/384Kbps/512Kbps/640kbps/768Kbps/1M/1.5M/2M/2.5M/3M/4M/5M/6M/8M |
| Audio output | 1PCS RCA Port( line level , impedance : 1kΩ) |
| Audio bit rate | 16kpbs |
| Dual-stream | YES |
| Stream type | combine streams/ video stream |
| Playback resolution | AHD:4CH 720P 1CH@25FPS; AHD+IP: 2CH 720P+2CH 1080P 720P 1CH@25FP or 1080P 1CH@25FPS; IP:9CH 1080P 1CH@25FPS |
| Synchronous playback | 1/4CH |
| Hard disk | |
| SATA | 1*SATA |
| eSATA | No |
| Capacity | each port support max 4TB HDD |
| External interface | |
| Network interface | 1PCS RJ45 10M / 100M adaptive Ethernet port |
| Serial interface | 1PCS RS485 |
| USB interface | 2*USB2.0 |
| Alarm in/out | No |
| General | |
| Power supply | DC12V |
| Comsumption | ≤20W |
| Dmensions(W×D×H) | 59*12*38cm |
| Weight | ≤10KG |
| Optical glass parameters | |
| Material | Tempered glass |
| Thickness | 3MM |
| Surface abrasion resistance | Strong |
| Translucency | >88% |
| Homogeneity | Good |
| Touch screen specification | |
| Touch accuracy | 5mm |
| service life | more than 3 years |
| the fastest response speed | 17ms |
| the average response speed | 18ms |
| Resolution | 4096*4096 |
| Data Correction Technology | Support |
| Compensation Technology | Support |
| self-inspection | Support |
| Anti-electromagnetic interference | Support |
| LCD screen: AUO or BOE Original screen | |
| Display size | 21.5" TFT LCD |
| Aspect Ratio | 16:9 |
| Max. Resolution | 1920*1080 |
| Contrast Ratio | 1000:01:00 |
| Brightness(cd/m2) | 250cd//m2 |
| Adapter | Pin:100~240V/50~60Hz, Pout: 12V/5Adc |
| Manual | WIN10 interface manual |
P Product Photos
W What is the Effect image of our Products?
W What is the Applications of our products?
P Packaging &Shipping,Trade Terms
W Why choosing us?
A ABOUT US
O Our Certifications
O Our Exhibitions & Customers visiting
F FEEDBACK
C Customers from All over the World
H How to Contact us?
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company, Distributor/Wholesaler
Year Established
2008
Factory Size
Below 1,000 square meters
Total Employees
51 - 100 People
