Home > Products > KVR > Camera Security System IP Camera Video 16ch PoE NVR Recorder System Kit 16 CH PoE NVR,Support Max to 16TB
Camera Security System IP Camera Video 16ch PoE NVR Recorder System Kit 16 CH PoE NVR,Support Max to 16TB
- 15000 Set / Sets per Month
- Shenzhen
- Credit Card PayPal
- Supply of Sodimax financial escort vehicle in-vehicle wireless 4G monitoring solution
- Supply school student delivery vehicle 4G wireless video real-time surveillance video recorder
- 4-channel 1080P single SD truck-mounted video recorder supports 4G network GPS full real-time monitoring
- SD Card 1080P HD Car Video Recorder H.264 Car Video Surveillance Solution
- 1080P HD MDVR Wifi GPS 3G Digital Video Recorder for School Bus CCTV System
- SD Card 720P HD Vehicle DVR H.264 Car Alarm Monitoring Solution
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Hyking | Model Number: | NVR6216F |
Product Description
Camera Security System IP Camera Video 16ch PoE NVR Recorder System Kit 16 CH PoE NVR,Support Max to 16TB
Feature
1)4/9/16/25/32 Audio Input
2)No Alarm I/O
3)2*4T HDD
4)VGA/HDMI output
Record Solution:
5MP/3MP/1080P/960P/720P
Playback:
16ch 720P realtime or
9ch 1080P realtime or
4ch 3Mp @ 50/60FPS or
2ch 5Mp @ 25/30FPS
W What is the Specifications of our products?
Model | NVR6216F |
Video & audio input | |
Network video input | 16CH |
Video & audio output | |
HDMI output | 800x600,1024x768,1280x1024,1440x900,720P,1080P |
VGA output | 800x600,1024x768,1280x1024,1440x900,720P,1080P |
CVBS output | NO |
Audio output | 1PCS RCA Port( line level , impedance : 1kΩ) |
Video & audio code and decode parameters | |
Record resolution | D1/HD1/CIF/720P/960P/1080P/3M |
Playback resolution | 720P 380/450FPS 1080P 100/120FPS 3MP 50/60FPS |
Motion detection | Motion Detection Depend on NVR |
Synchronously playback channels | 1/4/9/16CH |
Record management | |
Record & Snapshot mode | manual recording, regular recording, motion recording, alarm recording, events recording |
Playback mode | regular playback,alarm playback,motion detection playback,events playback |
Backup mode | regular backup, events backup, manual backup |
Hard driver | |
Mode | 4*SATA |
HDD capacity | each port support max 4TB HDD |
External port | |
Voice intercom | 1PCS RCA Port(Level : 2.0Vp-p, impedance : 1kΩ) |
Internet port | 1PCS RJ45 10M / 100M/1000M adaptive Ethernet port |
USB port | 2*USB2.0 1*USB3.0 |
Alarm input | 16 |
Alarm output | 4 |
Network Management | |
Network protocol | NTP,SMTP,PPPoE,DDNS,FTP,ARSP,WIFI,3G |
Other | |
Power supply | DC12V |
Power consumtion(without HDD) | ≤26W |
Work temperature | -10℃--+55℃ |
Work humidity | 10%--90% |
Case | 1.5U |
Size(W*L*H(cm)) | 430*365*68mm |
Net weight(without HDD) | 3.1kg |
Gross weight(without HDD) | 4.35kg |
Color box size(L*W*H(cm)) | 48*44*13cm |
Packing(pcs/carton) | 5 |
Carton size (L*W*H(cm)) | 68*49*45cm |
Gross weight(kg) | 23.12kg |
*Design and specifications are subject to change without notice.
P Product Photos
W What is the Effect image of our Products?
W What is the Applications of our products?
P Packaging &Shipping,Trade Terms
W Why choosing us?
1. More professional, better quality.
We engaged in software & hardware development, manufacturing and sales for security & safe products.( CCTV camera, IP camera, DVR, NVR ) for about 10 years.
2. OEM/ ODM service available.
Any your idea on camera we can help you to design and put in solution.
3.Strong Tech support.
* Presale: product consultation and solution design can be provided.
* After sale: We offer a 2-years warranty, which includes maintenance and technical support for all the products. Within the warranty period, exchanges and free maintenance are provided. If any quality issues occur, please contact us for technical support via telephone, email, or any method available on our site.
* We can also provide customized products, project designs, our project partner like: Shell in Japan, Barranquilla Harbour in Colombia, Greece National Park..
3. Strict Quality Control :
All of our electronic parts will stay in constant temperature machines more than 48 hours before assembly, all products wiil be fully inspected before shipment.
with CE, ROHS, FCC approval.
A ABOUT US
O Our Certifications
O Our Exhibitions & Customers visiting
Camera Security System IP Camera Video 16ch PoE NVR Recorder System Kit 16 CH PoE NVR,Support Max to 16TB
F FEEDBACK
C Customers from All over the World
F FAQ
Q1. Can I get samples?
A1. Sure. We will appreciate it if you’d like to purchase samples for tests first. For sample order, there is no limit on MOQ. And we will send samples as soon as possible after confirming your payment.
Q2. Are you factory?
A2. Yes we are. We have our own factory, which can help you get factory direct selling products with competitive prices. We always monitor strictly the quality of products before they leave factory.
Q3. How about warranty period? If any problem, can I get enough support?
A3. All the products you purchase from us have 2 YEAR WARRANTY. If the product is broken during this time, you can ship the item to us to repair or you can keep it and we will send a total new one to you soon. With strong technical team, we can provide life-time and timely technical support whenever there is something wrong with our products.
Q4. Why the shipping cost is so much? How about delivery time?
A4. Before shipment, we will find the most reliable carrier for you to make sure of lowest freight cost and shortest lead time. As for the delivery time, it depends on the order quantity. Normally it would take 3-15 days for one order.
Q5. Can I become your sole distributor in my place?
A6. We appreciate that. And we will discuss about your market situation together and after confirmation we will send you a contract with detailed requirements about sales targets.
Q6. Can you give us enough brochures and ideas as promotion to our customers?
A6. Yes, we’d love to help you promote your business. Welcome to share your idea of your market status and we will give you valuable advice and detailed information you need.
Q7. Can you make OEM products for us?
Q8. Sure we can. Do not worry, we can print your logo both on the products and boxes. But we might ask for MOQ according to the real situation.
