Hot New Products for 2015 Poe Small ip Camera Module Wifi Home Security Survalence Camera

Hot New Products for 2015 Poe Small ip Camera Module Wifi Home Security Survalence Camera thumbnail-1
Hot New Products for 2015 Poe Small ip Camera Module Wifi Home Security Survalence Camera photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Hyking
Model Number:
HK-HH-T320-P
Contact Supplier Request Quote Chat Now
Shenzhen KingCCTV Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Hyking
Model Number HK-HH-T320-P
Type IP Camera
Style Dome Camera
Sensor CMOS
Technology NetWork
Special Features Waterproof / Weatherproof

hot new products for 2015 poe small ip camera module wifi home security survalence camera

hot new products for 2015 poe small ip camera module wifi home security survalence camera

Product Description

Application

Suitable for hotels, supermarkets, offices, corridors, stairways and other indoor surveillance sites.



Key Features

  • Maximum pixel:2.0M, Max resolution:1920×1080, output Real-time Full HD 1080P image
  • Excellent low light performance
  • 3D smart noise reduction function
  • 1/3" Progressive Scan CMOS, Capture motion images without jagged
  • Built-in 2.8-12mm zoom lens
  • Two-axis adjustable, easy to install construction
  • Local CVBS video output , easy installation adjustment
  • H.264/MJEG is optional, dual streaming, low bandwidth, and high quality.
  • Support two-way talking
  • Support Micro SDHC card storage;SD2.0 standard,maximum storage 32G
  • Multiple network protocol support, adapt to the LAN / WIFI Mobile
  • Support motion detection, network fault detection,alarm recording,image snapping
  • Support 4 areas privacy mask
  • Biilt-in Web Server,Support IE video browsing,Parameter configuration, upgrade, user rights management
  • Small shell,space saving
  • User-friendly design, installation convenience
  • Power supply DC12V/1A
  • Support POE power supply
  • Support ONVIF protocol
Specification



Hardware
Network chip Lan Realtek 10/100M BASE-TX Self-adapting
Sensor 1/3" Progressive Scan CMOS
Effective pixel 1920(H)×1080(V)
Min.illumination

Color Mode:0.1Lux /F1.2  B/W Mode:0.001Lux/ F1.2
S/N ≥50db(AGC OFF,Weight On)
Day/night Auto,dual IR-Cut filter
Auto electronic shutter 1/25—1/100000sec,Slow shutter:1/2,1/4,1/8,1/12sec
Interface
Optical Lens Interface Φ14
Lens Manual zoom
Focal length 2.8-12mm
Auto talkback 1 channel MIC input, External access, 3.5 mm audio interface
Audio Output 1 channel linear output, 3.5 mm audio interface
Storage Interface Micro SDHC card supports video storage and image snapping; SD2.0 standard,maximum storage 32G(Optional)
Network Interface Lan 10/100M BASE-TX,RJ-45 connector
I/O 1-channel input, Normally Open/Normally Close modes adjustable; 1-channel output, 120VAC 1A/24VDC 1A,1 RS232 interface
Audio video encoding
Video Compression H.264 Main Profile;MJPEG/JPEG Baseline
Resolution Master Streaming 1920*1080,1-25(30)fps/sec 1280*960,1-25(30)fps/sec 1280*720,1-25(30)fps/sec
Second Streaming 640*480,1-25fps/sec 320*240,1-25fps/sec 160*112,1-25fps/sec
Video Bitrate 32Kbps~16Mbps,Supports CBR/VBR
Title OSD Supports channel name, date, and video stream information overlay;OSD location is adjustable
Audio Compression G.711, G.726,support 32 K stereo
Data transmission and storage
Data storage Video and Image
Recording Recording set up to record by motion trigger,alarm trigger, manual, or schedule
Alarm Output FTP,E-mail, Explorer, Software
Network protocol TCP/IP,UDP,RTP,RTSP,RTCP,HTTP,DNS,DDNS,DHCP,FTP,NTP,PPPOE,SMTP,UPNP
Wireless protocols(-W) 802.11b/g,Supports WEP,WPA,WPA2("-w" model supports)
ONVIF protocol Support
Remote View Computer IE 6.0 or up, max 10user
Mobile Phone Windows Mobile,Symbian,iPhone
General Parameters
Operating Temperature -10℃ - +55℃
Operating Humidity 0% - 90%
Power DC12V/PoE(-POE)
Power Consumption 5W(MAX)
Dimension Φ145*104(H)mm
Weight 0.6KG




Support Google Chrome browser

 hot new products for 2015 poe small ip camera module wifi home security survalence camera



Support IE browser

hot new products for 2015 poe small ip camera module wifi home security survalence camera



Support Firefox browser

hot new products for 2015 poe small ip camera module wifi home security survalence camera



Our Services



1. Any inquiries will be replied within 24 hours.

2. Professional CCTV products manufacturer, welcome to visit our website:

3. OEM/ODM Service:

 Both OEM and ODM services are available and we can also print your logo and make your

 own packaging according to your requriements.

4.After-Sales Service:

 1) All the products will be strictly Quality Checked in house before packing.

 2) All the products will be packed well before shipping.

 3) All the products have 2 years warranty.

5. MOQ:

 sample order, there is no MOQ.

6. Fast delivery:

 Sample order in stock, 3-15 days delivery time based on quantity afer receiving the payment.

7. Payment:

 You can pay the order via: Paypal,T/T, Western Union.

8. Shipping

 We have strong cooperation wiht DHL, TNT, UPS, FEDEX, EMS, China Air Post.

hot new products for 2015 poe small ip camera module wifi home security survalence camerahot new products for 2015 poe small ip camera module wifi home security survalence camerahot new products for 2015 poe small ip camera module wifi home security survalence camerahot new products for 2015 poe small ip camera module wifi home security survalence camerahot new products for 2015 poe small ip camera module wifi home security survalence camera

hot new products for 2015 poe small ip camera module wifi home security survalence camera







Advantages

Our Domain Customer



hot new products for 2015 poe small ip camera module wifi home security survalence camera

 We have accomplished the following big projects:

  • CCTV Surveillance for Greece National Park
  • CCTV Surveillance for Jewish Historical Museum Amsterdam
  • CCTV Surveillance for Barranquilla Harbour in Colombia
  • CCTV Surveillance for Shell in Japan

  Our products are extensively sold to more than forty countries and regions from 2004.



hot new products for 2015 poe small ip camera module wifi home security survalence camera
