Large Capacity Basket Centrifuge / Two-Stage Pusher Salt Centrifuge
Description:
Model PP Two-stage Pusher Centrifuge is a kind of perforated basket centrifuge, both continuous and effective. The mixture to be separated is fed through the feeding pipe and the distributor continuously and evenly into the first stage basket. Most of the mother-liquor in the feed, acted on by centrifugal force, departs through the sieves into the liquor-collecting casing where it will be discharged out of the machine. The first stage basket rotates and reciprocate, pushing the formed product cake into the second stage basket .The cake can have sufficient retardation in the centrifuge with being acted on by more centrifugal force, and therefore, the desired humidity of the cake can be guaranteed. Afterwards, the cake is continuously discharged out of the basket. In case of high purity for the solid product, the effective washing can be carried out in the centrifuge. If necessary, the washing agent and the mother-liquor can be discharged separately.
Technical parameters of PP-40
Equipments |
2 stage pusher centrifuge |
|||||
Spec. |
HR-40 |
Qty |
set |
|||
|
Technical parameters
| ||||||
1 |
Basket diameter |
290/360 mm |
||||
2 |
Basket Rotate Speed (Max) |
2500r/min |
||||
3 |
Stroke of Pusher Mechanism |
40-80times/min |
||||
4 |
First, second stage mesh aperture (as per the material) |
mm ,mm |
||||
5 |
Separation Factor |
586-728 |
||||
6 |
Main motor
|
Spec/Power |
11-15KW |
|||
|
|
Installation type |
Horizontal |
|||
|
|
Protection class |
IP54/F1 |
|||
|
|
Electrical power |
3 phase 380V/50Hz AC |
|||
7 |
Oil pump motor
|
Spec/Power |
5.5-7.5KW |
|||
|
|
Installation type |
Horizontal |
|||
|
|
Protection class |
IP54/F1 |
|||
|
|
Electrical power |
3 phase 380V/50Hz AC |
|||
8 |
Oil pump |
Spec. |
NB4C100F |
|||
|
|
outflow |
100ml/turn |
|||
|
|
Maximum pressure |
2.5Mpa |
|||
9 |
Overall size |
2346mm×1090mm×1006mm |
||||
10 |
Weight |
2600kg |
||||
11 |
Shell type |
open |
||||
12 |
Output |
3T-5T/h(sea salt) |
||||
13 |
Moisture content after separation: |
3-4%(sea salt) |
||||
14 |
Object processed |
Sea salt |
||||
Technical parameters of PP-50
Equipments |
2 stage pusher centrifuge |
|||||
Spec. |
HR-50 |
Qty |
set |
|||
|
Technical parameters
| ||||||
1 |
Basket diameter |
438/500 mm |
||||
2 |
Basket Rotate Speed (Max) |
2000rpm |
||||
3 |
Stroke of Pusher Mechanism |
40-80times/min(can be adjust) |
||||
4 |
First, second stage mesh aperture (as per the material) |
mm ,mm |
||||
5 |
Separation Factor |
1119 |
||||
6 |
Main motor
|
Spec/Power |
45KW |
|||
Installation type |
Horizontal |
|||||
Protection class |
IP54/F1 |
|||||
Electrical power |
3 phase 380V/50Hz AC |
|||||
7 |
Oil pump motor
|
Spec/Power |
22KW |
|||
Installation type |
Horizontal |
|||||
Protection class |
IP54/F1 |
|||||
Electrical power |
3 phase 380V/50Hz AC |
|||||
8 |
Oil pump |
Spec. |
SNE/A280 |
|||
outflow |
480ml/turn |
|||||
Maximum pressure |
2Mpa |
|||||
9 |
Overall size |
3660mm×1420mm×2078mm |
||||
10 |
Weight |
4400kg |
||||
11 |
Shell type |
open/seal(can be selet) |
||||
12 |
Output |
≥12T/h(sea salt) |
||||
13 |
Moisture content after separation: |
4%(sea salt) |
||||
