JMLDP Starch Separator , 30000LPH Wheat Starch B Concentration Disc Separator
Description:
The starch separators are disc separators with high speed and continuous nozzle discharge. They are mainly used for protein separation in the starch industry, like corn starch, sweet potato starch, cassava starch and potato starch, etc. for purifying starch, previous concentration, separating protein and recovering starch in starch production and also separating two-phase liquid-solid, recovering concentration or purifying, such as bleaching earth, recovering pulp, waste water, etc.
All the parts of the separator contacting the materials are made of stainless steel, therefore it meets the requirement of food hygiene. The design production and acceptance check are complied with JB/T6419 "Disc Starch Separator".
In today's art,3phase decanter is mainly used for separate starch A,B starch gluten and liquid pentosan,AT present,this 3phase decanter is mainly produced by FLOTTWEG,WESTFALIA ,Alfa Laval.
Commonly,before separation,Wheat starch B with 1.5-3Be waste,and after the nozzle separator treatment,the underflow concentration is 3-10Be.
Competitive Advantages:
- with high speed,
- accurate dynamic balancing,
- long time with low vibration,
- safety and security.
- Continuous working
- Nozzle discharging
Specification:
Discharging type |
Nozzle continually discharging |
|||
| Model | PJMLDP350 | JMLDP450 | ||
Bowl rotating speed |
rpm |
4600 |
4450 |
|
Max diameter of bowl |
mm |
350 |
|
|
Separation factor |
/ |
4726 |
4944 |
|
capacity |
m³/h |
8~12 |
15-30 at starch 5-7Be |
|
Outlet pressure of clear liquid |
Mpa |
0.05-0.15Mpa |
≤0.2 |
|
Motor power |
kw |
15KW |
30 |
|
N.W. |
kg |
812 |
1327 |
|
export |
dimension of package |
L×W×H |
1370mm×1340mm×1610mm |
450*1120*1470
|
G.W. |
kg |
1000 | 2150 | |
Structure:
1. upper sealing cover 2.O-sealing ring 3.small lock ring 4.bowl cover
5. upper lock ring 6.O-sealing ring 7.discs 8. Distributor
9. O-sealing ring 10.Spray pipe cover 11. Spray pipe cover 12. Distributor cover
Starch flowchart
Application:
- wheat starch,
- Corn starch,
- Sweet potato starch,
- cassava starch
- potato starch,
- bleaching earth recovering pulp etc.
