PID control auto-tuning digital thermostat
1. Universal signal input: K, J, R, S, B, T, N, E, RTD: PT100, CU50, CU100 ,4-20mA DC, 0-50mV , 0-400Ω ect.
2. Main control output: Relay , SSR , 4-20mA, 0-10V DC , SCR
3. Alarm relay output: 2 alarms relay output
4. Power supply: 100-240VAC/DC or 24V DC
5. Optional RS485 communication .
6. Optional 4-20mA or 0-10V DC analog output.
Please click here to view more products.
| Parameter | Specification |
| Power supply | 100-240C DC |
| Accuracy | 0.5%F.S±3 digital 25℃ |
| Total current | <30mA(220VAC/50Hz) |
| Resolution | 0.1°C or 1°C selectable |
| Transmit output | 4~20mA transmit current,load resistance 600Ωmax |
| Dielectric strength | Among power supply terminal,relay contact point, signal input terminals>2000VAC 50Hz/1min |
| Alarm output | Relay output: capacity 1A/250VAC |
| Control mode | ON-OFF control, PID heating and cooling control |
Auxilary voltage output |
DC 24V<30mA |
| Panel protect level | IP65 |
| Working ambient | 0~50℃ 45~80%RH |
| Storing ambient | -10~60℃ 25~85% RH |
Note: If there is any change, please subject to the drawing on the meter.
Package details: 1pcs/inner box, 50pcs/carton
carton size: 378*346*285mm
Shipping: FedEx, DHL, TNT, UPS, EMS etc, by air, by sea... any way you prefer.
Sommy Automation Group Shares Co., Ltd is a professional manufacturer of various electrical and industrial instruments since 1988, which located in both Hongkong and mainland of China. SOMMY have six automatic production line with 15,000 square meters manufacture center. It integrates research and development, production and sales into a whole system. SOMMY enjoy good reputation both in domestic and foreigh automation and electric field for many years.
Sommy products mainly include: electricity transmitter, power recorder, flow totalizer, temperature controller, digital counter and timer, frequency/RPM meter, solid state relay and various sensors etc.
With principle of " Quality fist, technology guidance", we have made great success in designing various new products. We focus on quality and after-sales service of our products all the time.
Welcome enquiry and cooperation ! We will be always at your service!
