Intelligent Online Conductivity Controller
- 10000 Piece / Pieces per Month
- Zhongshan/Ningbo/Shanghai/Guangzhou/HK
- T/T
Product Details
| Place of Origin: | China | Brand Name: | OEM | Model Number: | EC-450 |
Product Description
Intelligent Online Conductivity Controller
On line conductivity controller, conductivity monitor, conductivity meter
Model: EC-450 (Aupgrade product of CM-230 Conductivity Controller)
Features & application:
- Keyboard setup for measuring range conversion and conductivity cell constant input and high limit relay output.
- Medium temperature display
- Digital temperature compensation
- Isolation 4-20mA current output
- Apply to on-line monitoring and control for electrodialysis, reverse osmosis, ion exchange system, water cooling system, and general industrial water.
Main technical parameters:
Measuring range | 0~20/200/2000 μ S/cm; 0~20/200/2000 ppm; 0~20 mS/cm |
Accuracy | 1.5% (FS) |
Temperature compensation | Normal temperature: digital temperature compensation, with 25°C as the reference temperature High temperature: digital temperature compensation, with 90°C as the reference temperature |
Medium temperature | Normal temperature: 0~50℃ High temperature: 70~100℃ |
Auxiliary electrode | 1.0cm-1 |
Display | 3.5-bit backlit LCD |
Current output | Optoelectronic isolation 4~20mA |
Control output | ON/OFF high limit relay |
Power supply | AC 110/220V±10% 50/60Hz |
Working conditions | Ambient temperature: 0-50℃; Relative humidity:≤85% |
| Dimensions | 48x96x100mm (height*width*depth) |
Hole size | 45x92mm (height*width) |
| Install | Panel mounted |
Sommy Automation Group Shares Co., Ltd is a professional manufacturer of various electrical and industrial instruments since 1988, which located in both Hongkong and mainland of China. SOMMY have six automatic production line with 15,000 square meters manufacture center. It integrates research and development, production and sales into a whole system. SOMMY enjoy good reputation both in domestic and foreigh automation and electric field for many years.
Sommy products mainly include: electricity transmitter, power recorder, flow totalizer, temperature controller, digital counter and timer, frequency/RPM meter, solid state relay and various sensors etc.
With principle of " Quality fist, technology guidance", we have made great success in designing various new products. We focus on quality and after-sales service of our products all the time.
Welcome enquiry and cooperation ! We will be always at your service!
