CG series bar counter
Sommy CG economic flame proof digital counter can be used widely in the industries of production counting , packing, printing, textile, papermaking, petroleum, chemical engineering, metallurgy, etc.Multi-output modes to realize various of accassion demands. Counting length/quantity/timing via pulse input signal.
Features:
1.Button setting, easy operation
2.High performance, micro processor as control core
3.High accuracy, good high anti-interference
4.Power fail memory function, dual line 6-bit display
5.With four output modes( F,R,N,C)
6.Panel size(mm): 4: 48HX48W 7: 72HX72W 8:48HX96W
Model Indication
CG --0----0:Design code
-------- Display digit: 6digit
------------ Alarm output: B: one alarm
---------------- Ouput: R:relay
---------------------- Panel size: 4:48H*48W, 7: 72H*72W, 8:48H*48W
------------------------------ CG series digital counter
Model Slection
| Model | Dimension(mm) | Counting Digit | Alarm Output | Power Supply |
| CG4-RB60 | 48W*48H*100L | 6 | one upper limit alarm | 220VAC |
| CG7-RB60 | 72W*72H*100L | 6 | one upper limit alarm | 110/220VAC |
| CG8-RB60 | 96W*48H*100L | 6 | one upper limit alarm | 110/220VAC |
Technical Parameters
| Parameter | Specification |
| Power supply | AC220V/AC110V/DC24V |
| Total Consumption | <4W |
| Coefficient set range | 0.01-9999.99 |
| Counting range | 0.01-999999 |
| Relay capacity | 250V AC/3A |
| Auxiliary power output | DC18V+/-5V(<=25mA) |
| Insulation strength | 1.5KV/M |
| Count input speed | <=1/30/300/1000Hz four gears to choose |
Connection Drawing
Cargos support to delivery by Express/ Air Freight/ sea transport , shipping way will be choosed according to customers' demands.
1. We offer 3 years warrany period for all of our products.
2. We offer free pre-sales and after-sales service , please call to our technical support line :400-8866-986 or 86-760-88722603 if have any quesiton.
3. We offer OEM and ODM service for you , also offer design and reasearch new product for you .
4. We offer price , promotion and technical support , if you want to be our distributor in your country or region
