6 Digit textile counter meter / cable length measuring meter counter can be used in textile industry , packing industry , ant othe industrial field , with the same function as Autonics
Features
1.High speed counter , counting speed is up to 10kcp
2. Dual line 6 digit display
3. With counting up/ down, timing function, 8 kinds of output modes
4. Selectable input signal pulse width
5.Thickness only 64mm, save installation sapce
6. Panel size: 160WX80HX100Lmm , other size is available
* The same function as Autonics CT counter
Model Illustration
Technical Specification
Power supply |
AC100-240VAC 50/60Hz 24V power supply can be ordered |
Data storage |
10 years |
CPS of INA, INB |
1cps, 30cps, 1kcps, 5kcps, 10kcps selectable |
Sensor power |
Below 12VDC±10% 100mA |
Input pulse width |
Reset input: 1ms or 20ms selectable |
Temperature |
-10°C~50°C |
INA, INHIBIT, RESET, BATCH RESET, 1ms or 20ms selectable |
Relay capacity |
NO: 250VAC 3A Impedance |
|
|
Input |
To select voltage input or non-voltage input. Voltage Input: input impedance is 5.4 KΩ, H is 5-30VDC, L is 0-2VD Non-voltage input: short circuit impedance is max. 1 KΩ, residual voltage is max.2VDC, open impedance is min.100 KΩ |
NC: 250VAC 2A Impedance |
|
One-shot output |
10/20/100/200/500/1000/2000/5000ms |
SSR capacity |
Max.30VDC, 100mA |
Application
