Automatic Packing Machine With Secondary Packaging

Automatic Packing Machine with secondary packaging

Machine Introduction

The packing machine is mainly to complete the packaged pouch products (150~1000g) by request (order form: vertical arranged separately) neatly into the bag, sewing bag out of the automatic packaging process. In order to achieve a small package from the bulk material to a woven bag, full automatic operation, saving manpower, material and financial inputs, to reduce production costs, improve production efficiency, the unit is widely used in washing powder, salt, seeds , milk powder and other powder, granular packaging machine is the first choice for major companies.

Main Parts

Equipment basically consists of the double inclined conveyor, high speed conveyor, counting machine, woven bag automatic packaging machines, sewing machine, end product conveyor.

Working process

Production process: sackets →horizontal conveyor →Double slope conveyor → high speed conveyor →bag counting machine →automatic bag feeding machine →auto sewing machine →end woven bag putout

Advantages

1. Automatic plastic materials can be realized to enhance small package, measuring, bag making, filling, printing, sealing, finished out of the fully automated.

2. Bag automatic packing machine can automatically on the bags, open bags, counting, filling, moving out, into automatic sewing machine sewing automatically. The packaging process to achieve unmanned.

3. The touch screen control unit, operation, specifications change, maintenance is very convenient, safe and reliable.

4. Can be arranged to achieve a variety of forms to meet the needs of our customers.

Main technical parameters

1 Packaging range: 150g~1000g sachet products

2. Packaging Materials: paper bag,woven bag (lined with PP/PE film)

3. Packing speed:4~14 woven bags/min,( 40~85 pouches/min)

  (speed slightly changed according to different products)

4. Ranking form: Single bag dropping silo,single-row or Horizontal column placement
