stainless steel brewery equipment for restaurant
Our company is a private enterprise integrating with R&D, processing and engineering installation which is specialized in manufacturing of beer brewing equipment.
- Available with polished stainless steel brewhouse vessels
- Available with steam heating
- Modular brewhouse design, available either in a 2-Vessel version (brewkettle/whirlpool and mash/lauter tun, shown above), or 4-Vessel version with separate brewkettle, whirlpool, mash tun and lauter tun.
- Optional hot and cold liquor tanks are also available
Brewing is typically divided into 9 steps: milling, malting, mashing, lautering, boiling, fermenting, conditioning, filtering, and filling.
The mashing-lautering-boiling-whirlpool take place in the brewhosue, turn the malt into wort.
In order to provide the one-stop service, we could help you purchase the yeast, hops and other related raw materials for you.
Brew house unit :
1) Two mashing tanks : Mash tun/Lauter pot and Kettle/Whirlpool tank (Standard Configuration) Combined mashing tanks and three mashing tanks can be chose.
2) Power Controller : Control and show the temperature and time for the tanks.
3) Wort heat exchanger, yeast adding tank and oxygen filling device, hops adding device, etc.
4) Steam condensing device inside of the room (Heating method can be customized)
5) The raw materials for China, pipeline & valves with German standard;
The motors adopts ABB/Siemens brand , it is more convenient for the customer during operation.
1.Inner are of international standards of quality 304 stainless steel material, high-pressure polyurethane foam insulation, the jacket in accordance with customer requirements, can be polished stainless steel, matt, carbon steel, the form of spraying.
2.The application of international standardized fermented beer production technology, a wide range of temperature control application technology, mirror polishing inside the tank, up to ≤0.8u≤0.6um≤0.2um polishing quality standards, fully meet the PLC automatic cleaning and disinfection of the controlled system requirements.
3.Fermentor cooling jacket at the same time meet the needs of the country the world’s technical standards, the provision of Maitreya paneles, arched passages spinulosa Watt Jacket channel heat exchangers and other methods to meet different cooling media and the pressure of the heat exchange technology needs.
Material: stainless steel AISI 304
thickness: 3mm
Inner surface treatment: cold-rolled plates , 2B surface treatment, welds grinded to Ra 0,8µm.
External surface treatment: cold-rolled plates grinded to SBCooling:
Cylinder: 3 cooling-sections
Conical bottom : 1 cooling-section
Working pressure in cooling-sections - 1,5 bar
Insulation: Polyurethane - thickness 150 mm, density 1,09 g/cm³:both cylinder and conical bottom
External-Jacket: Stainless steel plate - thickness 1,5 mm, both cylinder and conical bottom
Working pressure: 1,5 bar in cylindrical-part (filled-up tank, at 20°C)
Shadowless Manway |
Thru the Wall Spray Ball |
CIP Lines |
Ball Valve for CIP |
Pressure Relief/Vaccumm Valve |
Rotating Racking Arm with Ball Valve |
Pull Handle Butterfly for Drain |
Thermometer |
Thermowell |
Sampler Valve |
Three-layer with dimple jacket and 60 °Conical Bottom |
Solid round Legs |
Pressure Gauge |
Insulated Polyurathane Filled |
Mirror polished,no rough edges |
Complete brewery equipment description:
1)Raw Materials Pretreatment Department;
2)Mashing Treatment Department;
3)Cooling Treatment Department;
4) Fermentation Treatment Department;
5) Filtering Treatment Department;
6) CIP Treatment Department;
7) Beer distribution Department;
8)Electric controlling Department.
We can supply 50L,100L, 200L, 300L, 500L, 1000L ,2000L,3000L,5000L,10000L and so on capacity beer equipment.
Tell me your specifications and I will customize for you acccording to your requirements.
1. Q: Do your products could be customized?
A: Yes, the beer equipment could be customized.
2. Q: Do you supply after-sales service?
A: Yes, we could supply after-sales service. We have 6 full-time engineers and other 4 part-time engineers available to go abroad to train installing and brewing.
3. Q: How long will the full set of equipment be guaranteed?
A: Three years warranty for main machine, one year warranty for the accessories.
4. Q: Are you trading company or manufacture?
A: We are a professional manufacture of beer equipment in this field.
5. Q: How is the proportion of your domestic market and foreign market?
A: 40% for domestic market, and 60% for foreign market.
6. Q: How long will the full set of equipment be shipped to us if we order it?
A: It will take 30-40 days to produce the full set of equipment.
7. Q: What should we do if there are problems during the process of using the equipment?
A: Firstly, we will communicate through email, skype or telephone, but if any accessory parts lead to problem, the accessory parts will be posted to you. If problems cannot be solved by all above mentioned method, our engineer will go abroad to solve for you.
8. Q: Do you also sell raw materials of brewing beer?
A: Yes, we do. We sell different kinds of raw materials including hops, yeast and malt.
stainless steel brewery equipment with 300l 500l per batch
Our equipment is well designed by professional designer, and adjustable according to your request. The best material is used to product your machine. The equipment is carefully packed before delivering.
- LCL/FCL(20GP/40GP/40HQ)
- packed with plastic film in fumigation free wooden case or fixed with iron frame
- up to export standard, suitable for delivery
- customer's requirements available
We ensure every order will not live up to the customers' requirement. Every order will be check by the professional skilled engineer before shipping.
Professional Pre-service:
- We can supply design service free according to customers’ request.
- We can supply budget assessment service upon our many years’ experience.
- Customers are welcome to come to our plant base to visit and inspect, and we would like to give a warm reception.
Sound After-service:
- Our brewmasters or engineers are available to supply service at buyers’ appointed places.
- We will give timely effective instruction about application of equipment as best as we can.
- We supply turn-key project.
