Specifications
1.Table & Mold vibration2.Hydraulic system
3.Multifunction in one machine
4.Various high density block/brick
5.Manufacturer
Main Technical Parameter of ZS-QT10-15 Cement Block Machine Plant | |||||
Overall Size(mm) |
3600*3100*3300mm |
||||
Moulding Cycle |
15-18s |
||||
Power(KM) |
54KW |
||||
Area of molding |
1000*800mm |
||||
Height of molding |
40-230mm |
||||
Pallet size |
1060*860*25mm |
||||
Host weight |
14T |
||||
Master Frequency |
4500R/Min |
||||
Rated pressure |
36Mpa |
||||
Exciting force |
80-100KN |
||||
List of Theoretical Production Capacity | |||||
Proudcts |
Specifications |
Pc/Mould |
Pc/Day |
Pc/Year |
|
Standard Brik |
240*115*53mm |
52 |
99,840 |
29,952,000 |
|
Hollow Block |
390*190*190mm |
10 |
19,200 |
5,760,000 |
|
Multi-hole Brick |
240*115*90mm |
24 |
46,080 |
13,824,000 |
|
Pathway Brick |
200*100*60mm |
36 |
47,232 |
14,169,600 |
|
Charateristic of Our machine:
1.Multifunction in one machine:the machine can produce porous blocks,pavement blocks,river way bricks,slope protection bricks,road blocks,square bricks.
2.The block/brick machine used Japan Mitsuibishi PLC control system and Delta Touch Screen.
3.Use Double high-hynamic Proportional/Directional Valves to autuomatically adjust the oil flow and pressure.
4.Buffer the hydraulic cylinder
5.Guarantee production stability
6.USe Frequency Conversional Control Tehcnology,which controls the blcok making.
7.Use heat treatment on moulds.
8.Greatly improves the using lifetime of the machine by 50%
9.The machine is compact in struction,stable in performance,convenient to operate and maintain.The investment of this project occupies small land,with little investment but benefit is high,suitable for large or medium building materials enterprise to invest.
