Specifications
new manual block making machine1. Hot sale
2. Easy to operate.
3. Good quality.
new manual block making machine for hydraulic press
Main Technical Specifications of QT 4-15 Brick Machine | |
|
Production per Mould: |
4pcs/mould (Standard Block: 400x200x200mm) |
26pcs/mould (Solid Block: 240x115x53mm) | |
14pcs/mould (Porous: 240x115x90mm) | |
16pcs/mould (Holland Brick: 200x100x60-80mm) | |
Cycle Time: |
15-17 seconds |
|
Production per Shift (8 Working Hours): |
Hollow Block (400x200x200mm): 6752-7680pcs |
Solid Block (240x115x53mm): 43888-49920pcs | |
Porous (240x115x90mm): 23632-26880pcs | |
Holland Brick (200x100x60-80mm): 20864-23040pcs | |
Max. Vibrating Frequency: |
3000-4500rolls/minute |
Vibrating Force: |
80-100 KN |
Motors Power: |
35KW |
Machine Dimensions: |
4950X3500X2580mm (excluding electrical control box) |
Pallet Size: |
850X540X17mm |
Gross Weight: |
about 5.5T |
Raw Materials: |
crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, perlite, and other industrial wastes. |
Applied Products: |
concrete blocks, solid/hollow/cellular masonry products, paving stones with or without face mix, garden and landscaping products, slabs, edgers, kerbstones, grass blocks, slope blocks, interlocking blocks, etc. |
Applied Fields: |
widely used in buildings, road pavings, squares, gardens, landscaping, city constructions, etc. |
Main Features of Brick Machine
|
1) Uses Japan Mitsubishi PLC control system and Delta Touch Screen. A. Visualization screen with easy operation; B. Is able to set up, update and amend the production perimeters, to maximize the production output; C. Dynamic display of the system’s status, automatic trouble shooting and warning notice; D. Has automatic-locking function, avoiding mechanical accidents caused by operational mistakes; |
|
2)Uses high-dynamic proportional and directional valves, which automatically adjust the oil flow and pressure as per specific working requirements, to buffer the hydraulic cylinder when working; uses integrated highpressure and soft oil pipes, with easy installation; |
|
3) Uses multi-shaft rotating and compulsory feeding, which greatly improves the density and intensity of the blocks, and reduces the feeding time as well; |
|
4) Integrated structure of vibrating and moulding platforms, which reduces the weight of the machine, and improves the vibrating efficiency; |
|
5) Uses double-line aero vibration-proof system, which reduces the vibrating force on the mechanical parts, improves the using lifetime of the machine, and reduces the noise; |
| 6)Heavy-duty machine frame, which uses high-intensity steel and advanced heat treatment, is wear resistant. |
Brick Machine Process
The Service about Brick Machine
| Sale-in Service |
|
1. Supervise the construction of foundation which includes electricity, water and other related amenities; 2. Our engineer will help to train the managers and technicians. Course including: factory management, equipment maintenance, quality control, stocking, marketing etc;
|
| After-sales Service |
|
1. Set up individual client's archives with all their needs and detailed to be attended;
|
| Extended Service |
| 1. Free Control System Upgrade. 2. Constant equipment and moulds improvement. 3. Newsletter:onalert to the latest industry trends and application. 4. Always advise new technology and craftsmanship application. |
Professional term introduce:
1.Table vibration:
Brick Mahcine Energy from the vibration table through the pallet to the mixture, make the mixture density.
2.Pressure vibrating:
Pressure head of mould down to the top surface of concrete, at the same time vibration start. The Brick Mahcine work with pressure and vibrating.
3.Feed vibrating:
The Brick Mahcine operates with small vibrating when the material feeding car at the top of the mould frame, let the concrete easy to fall down to the mould frame.
4.Green block:
Brick just forming by the Brick Mahcine, without curing.
5.Demoulding:
Separate the finished block produced by Brick Mahcine from the mould.
Five advantages of Automatic Brick Mahcine:
Our Brick Mahcine, with harmonic cooperation between electrical and hydraulic machines functions, guarantee a reliable and high output production of concrete products.
1. The Brick Mahcine use Japan Mitsubishi PLC control system and Delta Touch
A. Screen, use Schneider and Omron relays and contactors:
Mitsubishi PLC, with great adaptability, guarantees the stability and reliability of the Brick Mahcine;
B. Deltan touch screen, with easy operation;
C. High-quality electrical components from Schneider and Omron;
2. The Brick Mahcine use Frequency Conversional Control Technology, which controls the Brick Mahcine:
A. Frequency Conversion Control: Our Brick Mahcine guarantees the precise and parallel movement between tamper head and mould, protects the products from transfiguration; increases the production rate by improving the vibrating efficiency;
B. Frequency controlled vibration: controls the instantaneous start and stop of the motors, to protect the motor from over-heating caused by constant working;
C. Our Brick Mahcine Power saving: 30%;
3. The Brick Mahcine use Double high-dynamic Proportional/Directional Valves to automatically adjust the oil flow and pressure
A. Buffer the hydraulic cylinder, to protect the cylinder from damage caused by inertia;
B. Guarantee production stability;
4. The Brick Mahcine 360° Multi-Shaft Rotating and Compulsory Feeding:
A. Speedy and rotating feeding, with uniform mixing, to make sure that the density and intensity of the products are guaranteed;
B. This uniform feeding is applicable for different kinds of raw materials and moulds;
5. The Brick Mahcine use heat treatment on moulds and main parts of the Brick Mahcine:
A. Heavy duty machine structure and wear resistant moulds;
B. The hardness reaches up to HRC 52;
C. Greatly improves the using lifetime of the Brick Mahcine by 50%.
Brick Machine
Brick Machine Production Line
Actual Brick Machine Line
Workshop
Our Brick Machine Customers
The Production and raw materials of Brick Machine
Dear customer, if you are interested in our Brick Machine, please kindly tell me the size of the block/brick/pavers you want to produce, and the production capacity per day/year, then I can recommend a suitable model to you. Welcome your contact!
