Specifications
1. Multifunctional2. Automatic
3. Stable in performance
4. High output, Save labors
5. Maintenance convenient
Main Technical Parameter of ZS-QT4-15 Shanghai brick Machine |
|||||
Overall Size (mm) |
3000*1800*2000mm |
||||
Molding Cycle |
15-18s |
||||
Power(KM) |
35KW |
||||
Area of molding |
650*400mm |
||||
height of molding |
40-230mm |
||||
Pallet size |
850x540x17-20mm |
||||
Host weight |
App. 5t |
||||
Master Frequency |
3000-4500R/Min |
||||
Rated pressure |
16Mpa |
||||
Exciting force |
60-80KN |
||||
List of Theoretical Production Capacity |
|||||
Products |
Specifications |
Pc/Mould |
Pc/Day |
Pc/Year |
|
Standard Brick |
240x115x53mm |
26 |
49,920 |
14,976,600 |
|
Hollow Block |
390x190x190mm |
4 |
7,680 |
2,304,000 |
|
Multi-hole Brick |
240x115x90mm |
14 |
26,880 |
8,064,000 |
|
Pathway Brick |
200x100x60mm |
16 |
23,040 |
6,912,000 |
|
Based on international advanced welding technology,mechanical parts made of high strength steel is very hard and durable against vibration.
Key electric parts,such as programmable controller,LCD touching screener,frequency converter and so on are from international famous brand with high reliability and long life cycle
360° Multi-Shaft Rotating and Compulsory Feeding:speedy and rotating feeding, with uniform mixing, to make sure that the density and intensity of the products are guaranteed.This uniform feeding is applicable for different kinds of raw materials and moulds
Use heat treatment on moulds and main parts of the machines:heavy duty machine structure and wear resistant moulds.The hardness reaches up to HRC 52
Hydraulic parts and seals parts on hydraulic pressure system are from Japan or Taiwan,which protects pressure discharging or leakage
Vibration frequency and vibration on molder can be adjusted as per different products or different craft work.(Such as low-frequency material feeding;high-frequency vibration).Auto materializes multi frequency on each production cycle to produce good quality products
The machine is compact in structure,stable in performance,convenient to operate and maintain.The investment of this project occupies small land,with little investment but benefit is high,suitable for medium or small building materials enterprise to invest.
Dear customer, if you are interested in our block making machines, please kindly tell me the size of the block/brick/pavers you want to produce, and the production capacity per day/year, then I can recommend a suitable model to you. Welcome your contact!
Update Date:2011-11-14 20:41:44
